Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > SW SERIES Cone Bending Rolls(6~30mm)

SW SERIES Cone Bending Rolls(6~30mm)

US$ 10,000 - 120,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Contact Supplier Request Quote Chat Now

Wuxi Shenchong Forging Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name sc

Model Number SW

Machine Type Roller-Bending Machine

Raw Material Sheet / Plate Rolling

Material / Metal Processed Other, mild steel, stainless steel, aluminum

Power Hydraulic

Automation Automatic

Extra Services Machining

Certification Other, CE, ISO9001, SGS

SW SERIES CONE BENDING ROLLS FOR PLATE METAL

This machine is the general equipment used for bending plates. Pre-bending and bending can be completed on the machine without U-turn. Plates can be bended to be tubular, arc or even cone-shaped work pieces with supplemental device. The machine is optimal equipment with four rollers to bend metal plates.

Features:

1. Pre-bending and bending can be completed without reversing end for end.
2. After plate fed, alignment can be finished by side rollers.
3. Plate can be leveled sketchily on the machine.
4. Surplus of pre-bending is short and all kinds of defective reel can be regulated.
5. It is convenient to bend cone-shaped work pieces.

Parameters:

Modal	Max. plate Thickness (mm)	Max. Pre- Bending thickness (mm)	Max. plate Width (mm)	Roll speed (m/min)	Min. diameter of Max. plate Thickness (mm)	Upper Roller Diamete (mm)	Bottom roller diameter (mm)	Main Motor power (KW)
SW11X-B-6×2000	6	4	2000	5.6	380	180	170	5.5
SW11X-B-6×2500	6	4	2500	5.6	450	230	200	7.5
SW11X-B-8×2000	8	6	2000	5.6	450	230	200	7.5
SW11X-B-8×2500	8	6	2500	5.5	500	240	220	11
SW11X-B-8×3200	8	6	3200	5.8	650	260	230	15
SW11X-B-12×2000	12	8	2000	5.5	500	240	220	11
SW11X-B-12×2500	12	8	2500	5.8	650	260	230	15
SW11X-B-12×3000	12	8	3000	5.8	750	300	260	22
SW11X-B-16×2000	16	12	2000	5.8	650	260	230	15
SW11X-B-16×2500	16	12	2500	5.8	750	300	260	22
SW11X-B-16×3200	16	12	3200	5.6	900	340	300	22

Note: Plate yield limit 245Mpa is benchmark for design, the technical parameters for your reference, if product mend, parameter alter, we will not inform you in addition.
