CE Mark 3 - Zone Thermal Shock Test Chamber for Automobile Parts Reliability Test
Thermal shock testing reveals an element or sample's behavior while undergoing rapid changes in temperature. Thermal shock chambers are often used for testing the resilience of microelectronic devices in the face of sudden temperature shifts. These thermal stress-testing chambers typically have two compartments for hot and cold, though some models offer and intermediate third chamber for ambient/room temperature. A thermal shock chamber will typically have a temperature between -80C and 200C. Thermal shock chambers can affect temperature changes of up to +/- 70C per minute. These high-throughput thermal shock testers often share attributes of other environmental test chambers, including humidity and vibration functionality.
| 3 Zone Thermal Shock Test Chamber | ||
| Specifications | Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | |
| Model | KTS-A Series | |
| 200A | ||
| Interior size | W(mm) | 670 |
| H(mm) | 600 | |
| D(mm) | 500 | |
| Exterior size | W(mm) | 1720 |
| H(mm) | 2000 | |
| D(mm) | 1850 | |
| Test weight(KG) | 15 | |
| Low Temp. chamber | -55ºC~-10ºC | |
| Pre-heat time | +20ºC~-55ºC ,Within 60 min | |
| Test. chamber | -40ºC~+150ºC | |
| High Temp. chamber | +60ºC~+200ºC | |
| Pre-heat time | +60ºC~+200ºC ,Within 20 min | |
| Recovery time | High-Temp Exposure 30 min | |
| Low-Temp Exposure 30 min | ||
| Recovery time within 5 min | ||
| Safety device | No fuse breaker, over pressureover heat and over current protection for compressor,over temperature protection, over load protection for blower, dry heat protection | |
| Standard accessory | Cable port(portΦ50mm)*1, shelves*2 | |
| Interior material | Stainless steel plate(SUS 304) | |
| Exterior material | Baked painting steel or stainless steel(SUS304) | |
| Insulation material | Rigid polyurethane Foam+glass fiber wool | |
| Refrigeration system | Water Cooled | |
| Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) | ||
| Controller | Panel:7-inch LCD Touch panel,Chinese or English display selectable | |
| Operation model:Program or fix point running | ||
| Memory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles. | ||
| Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit | ||
| Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV | ||
| Ambient Temp. | +5ºC~+35ºC | |
| Power | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | |
1. Housing: integrated structure, mono-block construction which comprises all systems necessary for operation. And the outer housing is made of good quality galvanized sheet steel which is inside and outside primered and painted to a standard finish with high quality materials. The exterior surface will have high wear resistance.
2. Test space: the internal test space will be made of non magnetic SUS-304 stainless steel with no paint. All the seams will be TIG welded and vapor tight. The surface has no light reflection.
3. Insulation: the insulation material will be of low 'k' factor, high intensity and non hygroscopic nature. The insulation will be multi layered with double vapor barrier. Asbestos free mineral fiber insulation will be used.
4. Door: fully-opened and single wing type, double silicone sealed, hinges and locks; the cold zone and hot zone each has a door; the test sample zone has a fully-opened single wing door.
5. One Emergency Stop outside the chamber.
6. Cable port: One dia. 50mm or dia.100mm porthole.
7. Power board and machine group positioning: in a frame placed behind the chamber.
Machine Parts
Name: Bock Compressor
Brand: Bock
Original: Germany
Compressor rack, high efficiency low energy consumption, low noise;
Electronic components
Name: Electric cabinet
Brand: Schneider, DANFOSS, Omron, Panasonic
Original: Germany, France, Japan
Top brand electronics, with full range of protection include overheat of blower fan motor, earth leakage protection, load short circuit protection, over temperature protection, over pressure protection and so on.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* Visiting our factory is highly welcomed.
After-Sales Service
* If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
