Specifications
CE standard stretch film machine1.pe,pp,pvc stretch film making machine
2.1 layer, 2 layer, 3 layer co-extrusion
DF-1000 CE standard stretch film machine
Stretch Film Machine
stretch and cling film machine
stretch film making machine
Use:
This unit uses LLDPE as main material and adopts several kinds of resins to manufacture the single/double-side self-sticky strech wrapping film.The film has good tensile strength,anti-pricking ability and impact strength. Its good shrinking memory function and self-sticky can make googs integrity to prevent goods from loosening and collapsing during transportation and being polluted bu dust. The transparency and tensile strength of this product can make the packaging beautiful,economical and practical. The film can be widely used in wrapping of palletized goods.It's a good substitute for hot shrinking packaging film during transportation.
Optional equipment
1.Auto loader
2. Dry hopper
3. Air shift
4.Auto winder changer
5. Auto screen changer
6.Glue pump
Main technical variables:
Item/Model |
1250mmDouble-layer |
1250mmSingle-layer |
Screw diameter(mm) |
65 |
75 |
L/D ratio of screw (L/D) |
30:1 |
30:1 |
width of die head (mm) |
1250 |
1250 |
Width of finished products(mm) |
1000(500*2roll) |
1000(500*2roll) |
Thickness of finished products (mm) |
0.008-0.05 |
0.008-0.05 |
Structure of film layers |
A/B |
-- |
Max output (kg/h) |
100 |
100 |
Linear speed of machinery (m/min) |
50-100 |
50-100 |
Total power (KW) |
140 |
120 |
Overall dimensions (L*W*H)m |
10*4*3 |
11*4.5*3 |
Weight (T)(About) |
8 |
8 |
