DF-1000 Single Double Layer Stretch Film Machine
US$ 24,000 - 36,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DF-50/55 Double-Layer Stretch Film MachineUS$ 6,000 - 18,000MOQ: 1 Set -
3 Layers Stretch Film MachineNegotiableMOQ: 1 Set
-
Full Automatic Stretch Film Rewinding MachineNegotiableMOQ: 1 Set
-
5%-10% Off Hot Sale Full Automatic High Speed Stretch Film Machinery In StockUS$ 10,000 - 50,000MOQ: 1 Set
-
CE Approved DF-1000 PE Stretch Film Making MachineUS$ 1,000 - 50,000MOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
PE
Screw Design
Double-screw
Automatic Grade
Auto matic
Place of Origin
Zhejiang, China
Brand Name
GUOTAI
Model Number
DF-50/55 Stretch film machine
Voltage
380
Power(W)
120kw
Dimension(L*W*H)
8000*3000*3000
Weight
7
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
main motor and take-up motor are controlled by inverterby pneumatic cylinder system to adjust the gap of roller
Main Technical Parameter:
Item/Model |
1250mmDouble-layer |
1250mmSingle-layer |
Screw diameter(mm) |
65 |
75 |
L/D ratio of screw (L/D) |
30:1 |
30:1 |
width of die head (mm) |
1250 |
1250 |
Width of finished products(mm) |
1000(500*2roll) |
1000(500*2roll) |
Thickness of finished products (mm) |
0.017-0.05 |
0.017-0.05 |
Structure of film layers |
A/B |
-- |
Max output (kg/h) |
100 |
100 |
Linear speed of machinery (m/min) |
50-100 |
50-100 |
Total power (KW) |
140 |
120 |
Overall dimensions (L*W*H)m |
10*4*3 |
11*4.5*3 |
Weight (T)(About) |
8 |
8 |
Dubble Layer
single layer
