Battery use laboratory climatic temperature humidity test equipment alibaba co uk
Constant high-low temperature humidity climate test chamber lab equipment are mainly and widely used for various types of testing such as prototype evaluation, research & development testing, production quality control testing, accelerated stress testing, reliability testing, failure analysis, and any other application where environmental simulation is needed.
| Environmental Temperature and Humidity Chamber/climate test chamber/machine/equipment | |||||||||||||||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | |||||||||||||||
| Model | KMH-R series | KMH-L series | KMH-S series | ||||||||||||
| 150R | 225R | 408R | 800R | 1000R | 150L | 225L | 408L | 800L | 1000L | 225S | 408S | 800S | 1000S | ||
| Temp. range | -20ºC~150ºC | -40 ºC~+150ºC | -70ºC~+150ºC | ||||||||||||
| Interior sizel | W(mm) | 600 | 700 | 700 | 1000 | 1000 | 600 | 700 | 700 | 1000 | 1000 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | 600 | 700 | 750 | 1000 | 1000 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | 460 | 480 | 800 | 800 | 1000 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 | 880 | 980 | 980 | 1280 | 1280 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | 1730 | 1890 | 1940 | 2160 | 2160 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | 1400 | 1460 | 1740 | 1750 | 1950 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | 7.5 | 7.5 | 8.5 | 14.5 | 14.5 | 9.5 | 10.6 | 18.5 | 18.5 | |
| Weight(KG) | 240 | 280 | 400 | 500 | 580 | 250 | 300 | 420 | 530 | 600 | 330 | 450 | 550 | 650 | |
| Humidity uniformity | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | |||||||||
| Heat up time | -20ºC~+100ºC,within 35 min | -40ºC~+100ºC, within 45 min | -70ºC~+100ºC,within 60 min | ||||||||||||
| Pull down time | +20ºC~-20ºC, within 45 min | +20ºC~-40ºC , within 60 min | +20ºC~-70ºC,within 80 min | ||||||||||||
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | ||||||||||||||
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, | ||||||||||||||
| Over temp. protect, over load protect of blower, dry heat protection | |||||||||||||||
| Control System | Balanced Temperature & Humidity Control System | ||||||||||||||
| Refrigeration system | Air Cooled (Water Cooled Type is option) | ||||||||||||||
| Hermetic compressor,Single stage refrigeration system | |||||||||||||||
| CFC-Free refrigerant(HFC-507/HFC-23) | |||||||||||||||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | ||||||||||||||
| Operation model :Program or fix point running | |||||||||||||||
| Memory capacity :120programs,1200steps, | |||||||||||||||
| All repeat 999 cycles, part repeat 99 cycles | |||||||||||||||
| Humidity Range | 20~98%R.H | ||||||||||||||
| Temp. constancy | ±0.5ºC | ||||||||||||||
| Humidity constancy | ±2.5%R.H | ||||||||||||||
| Temp. uniformity | ±2.0ºC | ||||||||||||||
| Interior material | Stainless Steel Plate(SUS 304) | ||||||||||||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||||||||||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||||||||||||
| Ambient Temp. | +5ºC~+35ºC | ||||||||||||||
| Wiring method | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | ||||||||||||||
|
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | |||||||||||||||
high-low temperature test chamber:
- Programmable setup is available, max 120 sets, 1200 segments and 999 cycles.
- The refrigeration units are supplied by Tecumseh(France).
- A large TEMI super induction LCD touch screen helps to perform operations more conveniently.
- A test graph indicator provides a continuous performance progress report.
- A P.l.D auto counter enables continuous immediate temperature and humidity error correction.
- A microprocessor control unit enables temperature and humidity fluctuation to be applied dividedly.
- A 5 cm port is centered on the left side of the chamber for ease of cable routing.
- Mist-free viewing window and interior light provide a hassle free viewing workspace.
- Swivel casters provide easy mobility and flexibility in a variety of laboratory conditions.
- Four-tiered safety protection system.
- RS-232 communication interface( optional). Personal computer can be easily connected to this testing equipment to enhance display testing status, testing results, program settings, operation log, etc.
What brand of the parts we use?
Compressor
Name: Bock Compressor
Brand: Bock(GEA)
Original: Germany
KOMEG use imported compressor from Germany with high efficiency low energy consumption, low noise.
Electronic components 1
Name: Electric cabinet
Brand: Schneider, DANFOSS, Omron, Panasonic
Original: GGermany, France, Japan
KOMEG use top brand electronics, with full range of protection include overheat of blower fan motor, earth leakage protection, load short circuit protection, over temperature protection, over pressure protection and so on.
Electronic components 2
Name: Oil seperator
Brand: EMERSON
Original: USA
Control System
Name: Controller
Brand: KOMEG/SAMWON
Original: China/South Korea
It can control temperature and humdity constantly such as thermo-hygrostat mounted on, termperature, humidity, respectively, by setting the PID values for each interval can be precisely controlled and easy control via PC or mobile is possible.
Our other main products:
climatic test chambers/ high-low temperature test chamber
2-zone thermal shock test chambers
3-zone thermal shock test chamber
walk-in test chambers
drive-in test chambers
burn-in rooms
aging test chambers
drying ovens
salt spray test chamers
ESS rapid temperature changer chamber
vibration test chamber
medical laboratory
