Cheap and good quality wood cnc stone diamond engraving bits
Features :
1.3KW air cooling spindle, with 3.7kw inverter
2,Taiwan HIWIN Linear guide for all axis (durable and high precision),
3,DSP control system (easy operation and high precision),
4,Welded steel structure, T structure, 10mm thickness beam cross,
5,double use working table: Vacuum & T-slot working table,
6,gear transmission for X, Y axis, Taiwan high precision TBI ball screw transmission for Z axis,
7,Double motors for Y axis, FL Stepper motor with 8 wires (top quality in China),
8,big strength stepper driver YAKO 2608
9, Tool sensor, Manual lubrication, Type3 Software.
10,All Electronic component are CE standard
Applications :
1.WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2.Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives
making.
3.Die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks,and other non-metallic mold.
4.Relief sculpture and 3D engraving
5.Cylindrical object
After sale service:
1,Within 7 days since your local customs clearance: if the cnc machine’s any parts has any problems, we will change it free.
2,Exceed 7 days since your local customs clearance but within warranty period: if the cnc machine parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.
3,Exceed warranty period: if the cnc machine parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.
4,We offer 24 hours technical support by call, email
5,Our technician can give you remote guide online(Skype or MSN) if you have any question
6,We can record videos of operating the cnc router machine
7,Free training course in our factory
8.Machine will be adjusted before it is delivered , operation disk/CD was included.
Parameters :
Description |
Parameter |
X,Y,Z Working Area |
2000x3000x200mm |
Table Size |
1480×3050mm |
X,Y,Z Traveling Positioning Accuracy |
±0.03/300mm |
X,Y,Z Repositioning Accuracy |
±0.03mm |
Table Surface |
Vacuum and T-slot working table) |
Frame |
Welded Structure |
X, Y Structure |
Rack and Pinion Drive, Hiwin Rail Linear Bearings |
Z Structure |
Hiwin Rail Linear Bearings and Ball Screw |
Max. Power Consumption |
(Without Spindle) 3.2Kw |
Max. Rapid Travel Rate |
33000mm/min |
Max. Working Speed |
25000mm/min |
Spindle Power |
3kw water cooling spindle |
Spindle Speed |
0-24000RPM |
Drive Motors |
stepper |
Working Voltage |
AC380V/50/60Hz,3PH (Option: 220V) |
Command Language |
G Code |
Operating System |
DSP System (Options: Ncstudio/Mach3 PC Software) |
Computer Interface |
USB |
Flash Memory |
128M(U Disk) |
Collet |
ER25 |
X,Y Resolution |
<0.01mm |
Software Compatibility |
Type3/UcancameV9 Software, (Option: Artcam Software) |
Running Environment Temperature |
0 - 45 Centigrade |
Relative Humidity |
30% - 75% |
Customers to visit our factory:
We are Professional CNC Router and Laser Machine Manufacturer and sincerely seeking for Global Agent & Distributors.
