cnc router 6090 for wood stone acrylic
Features:
The machine is the best choice for small piece materials working, and it is suitable for advertising working. It is good at engraving on brass, aluminum, plastic, acrylic, wood, MDF and other similar materials. Working with dust hood on all three axis, it can stop dust away from the rails and ball screws, and to keep the machine working for longer time
We use accurate LM linear (HIWIN) for Y axis, with options such as water cooling system or mist cooling system etc.
With T-slot table, holding the materials with clamps, you can do variety of high-precision works.
Performance parameter:
Number | Description | Parameter |
1 | X,Y,Z Working Area | 600mmx500mmx120mm |
2 | Table Size | 720mmX1140mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.01mm/300mm |
4 | X,Y,Z Repositioning Accuracy | ±0.01mm |
5 | Table Surface | T-slot Table |
6 | Frame | Welded Structure |
7 | X, Z Structure | Round Rails and TBI Ball Screw, |
8 | Y Structure | Hiwin Rail Linear Bearings and Ball Screw |
9 | Max. Power Consumption | 0.8Kw |
10 | Max. Rapid Travel Rate | 10000mm/min |
11 | Max. Working Speed | 6000mm/min |
12 | Spindle Power | 1.5Kw Water Cooling Spindle |
13 | Spindle Speed | 0-24000RPM |
14 | Drive Motors | Stepper System |
15 | Working Voltage | AC220V/50/60Hz, 1Phs |
16 | Command Language | G code |
17 | Operating System | DSP System (options: Ncstudio/Mach3 PC Software) |
18 | Computer Interface | USB |
19 | Flash Memory | 128M(U Disk) |
20 | Collet | ER16 |
21 | X,Y Resolution | <0.01mm |
22 | Software Compatibility | Type3/UcancameV9 software (Option: Artcam software) |
23 | Running Environment Temperature | 0 - 45 Centigrade |
24 | Relative Humidity | 30% - 75% |
25 | Packing Size | 1710mmx1250mmx1585mm |
26 | N.W. | 160KG |
After-sale service:
1, Within 7 days since your local customs clearance: if the cnc machine’s any parts has any problems, we will change it free.
2, Exceed 7 days since your local customs clearance but within warranty period: if the cnc machine parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.
3, Exceed warranty period: if the cnc machine parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.
4, We offer 24 hours technical support by call, email
5, Our technician can give you remote guide online(Skype or MSN) if you have any question
6, We can record videos of operating the laser machine
7, Free training course in our factory
8.Machine will be adjusted before it is delivered , operation disk/CD was included.
Application and samples:
1. WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2.Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3.die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
4.relief sculpture and 3D engraving
5.Cylindrical object
Products sample:
Our cnc routers' customization is available.
Our company has obtained CE, FDA and ISO certificates.
We promise to provide high quality product with competitive price!!
Our company has more than 10 years experience in manufacturing cncrouter, Laser Engraving & Cutting machine. And seventh year supplier on Alibaba.
