Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing

Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing

Name: Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing
Brand: Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing
SKU: 127574239

Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing thumbnail-1

Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing

Model Number:

EDFA1532

Contact Supplier Request Quote Chat Now

Hangzhou Eric Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai/shenzhen/ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing

Model Number EDFA1532

Eric 1550nm Optical CATV Power Amplifier/CATV Amplifier Housing

Product description

EDFA1500 series is a CATV booster optical amplifier with gain spectrum band within 1530~1560nm. It has low noise figure, high-saturated output power. It is applicable for central bureau, sub-bureau and line relay, as well as other optical communication network.

Features

1) Dual mechanic cooler in the housing and inside iron box to protect the laser. Work a long time.

2) RJ45 port for SNMP remote management.

3) RS232 for local management.

4) Adopts JDSU, Fitel and Bookham Pump laser.

5) Good stability, VFD or LED displays the working conditions, good trouble alarm system.

6) Power supply 90V ~ 265V AC or -48V DC for the user’s choice.

7) Max output can reach 27dBm.

Specification

Items	Parameter
Items	1500-14	1500-15	1500-16	1500-17	1500-18	1500-19	1500-20	1500-21	1500-22~27
Output (dBm)	14	15	16	17	18	19	20	21	22~27
Output (mW)	25	32	40	50	63	80	100	125	160~500
Input(dBm)	-3 ~ 10
Wavelength(nm)	1530 ~ 1560
Output Stability(dB)	≤0.2
Polarization Sensitivity	<0.2 dB
Polarization Dispersion	<0.5 PS
Optical Return Loss	≥45 dB
Fiber Connector	FC/APC or SC/APC
Noise Figure(dB)	<4.5(0dBm Optical Input)
Network Interface	RJ45(SNMP) / RS232 / RS486
Power Consumption	50 W
Power Supply(V)	220VAC(110 ~240) or -48VDC
Working Temp(°C)	-20 ~ +85
Size(″)	19″* 15″* 1.75″
Weight(Kg)	5.0

Contact us

We highly appreciate your any enquiry by email, or instant message ,

We will reply your email within 12 hours .

please feel free to call us at any time if there is any questions.

Transportation

All available shipping ways could be applied. by express,air .

Appointed shipping company or our own forwarders all could be used in shipment.

Full-way tracking the items for you before the goods arrive .

Our Services

1.Any inquiries will be replied within 24hours

2.Professional manufacturer.

3.OEM/ODM avaliable:

1)Silk print logo on the front panel

2)Customized Color box

3)Customized housing

4)Any your idea on our equipments we can help you to design and put it into production

4.High quality, fashion designs, reasonable and competitive price, fast lead time

5.After-sale service:

1)All products will have been strictly quality checked in house before packing

2)All products will be well packed before shipping

3)All our products have 1year warranty.

6.Faster delivery:

Sample order 1~3working days, and 3~7 working days for bulk production

7:Payment:

You can pay fro the order via: T/T,Western Union, Paypal and others, or place order directly on Aliexpress

8.Shipping:

We have strong cooperation with DHL, TNT,UPS,FEDEX,EMS and China Air Post

You also can choose your own shipping forwarder.

Certificates

Our Factory

About us

We are manufacturer of all CATV optical equipments such as FTTH optical receivers, Optical transmitters, Optical amplifier-EDFA , SAT-IF optical transmitters and receivers, Optic Transceiver Module and Optical Fiber Test instruments.

If you need optical equipments,please contact with me without hesitation!
