CATV FTTH Optical onu Receiver
Description
ERH1000 Series product is designed for FTTH/FTTB or HFC applications. The general type ERH1085 has a normal output level 85dBuV per-channel for TV. The enhanced type ERH1095 provide higher level, 95dBuV with -7dBm input power and 3.5% optical modulation index.
Feature
1.CATV FTTH optical onu receiver
2.-8~+1dBm input power
3.85dBuV output
4.45MHz~1GHz
5.CE and RoHS
Downstream signal path | General | ||
Light Wavelength | 1260 ~ 1620nm | Power Consumption | 2.8W |
Optical Input Power Range | -10 ~ +3dBm | Voltage | 12V DC |
Frequency Range | 45MHz ~ 1GHz | RF Connector(s) | F Female |
Output Level | 85 ~ 100dBuV(20dB adj.) | Optical Connector(s) | SC/APC |
Flatness | ±0.5dB | Dimensions(L×W×H)(mm) | 100×80×28 |
Slope | 0dB | Weight | 0.2kg |
Return Loss | 16dB | Operating Temp | -20 ~ 65°C |
Noise Figure | 51dB | ESD(RF) Port | 2KV |
CTB 59channels | ≥60dB |
| |
CSO 59channels | ≥58dB |
| |
Diagram
Drawing
