E10 Eric Micro Home Optic Receiver China Supplier

Name: E10 Eric Micro Home Optic Receiver China Supplier
Brand: Eric
SKU: 127572687
Availability: InStock

E10 Eric Micro Home Optic Receiver China Supplier thumbnail-1

E10 Eric Micro Home Optic Receiver China Supplier photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Eric

Model Number:

E10 optical receiver

Contact Supplier Request Quote Chat Now

Hangzhou Eric Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Eric

Model Number E10 optical receiver

E10 Eric Micro Home Optic Receiver China supplier

Features and Benefits

The E10 is a high performance CATV optical receiver for converting TV signal from optical fiber network into RF signal over coax cabling in residential homes. This module features compact size, high CNR, low distortion, low power consumption, easy installation and cost effectiveness. It supports conventional analog TV RF as well as Digital Video Broadcasting signals. The E10 is the best choice to be used in combination with a managed Ethernet gateway to deliver FTTH triple play services. Its RF output On/Off control function makes it possible to remotely control the status of the module at subscriber”s location which enables smart supervision and management of the network from the Headend or central office.

Performance Characteristics
1. Automatic Gain Control(AGC).(Optional Function)

2. Compact integrated mechanical size.

3. Low distortion,high performance video quality.
4. Wide optical input range.
5. RF output signal On/Off remote control.
6. Remote powering.
7. Standard 75 ohm F connector.
8. Provide the interface of network services for FTTH application.

Technique Parameter

Item	Unit	Technical Parameter
Optical Parameters
Optical Receiving Power	dBm	-10 ~ +2
AGC Range	dBm	-7 ~ +1
Optical Return Loss	dB	> 45
Optical Receiving Wavelength	nm	1260 ~ 1620
Optical Connector Type		SC/APC
Fiber Type		Single Mode
Link Performance
C/N	dB	≥ 48	@Pin= -1dBm, Pout=80dBμV, 84CH PAL-D, OMI=3.8%
C/CTB	dB	≥ 65
C/CSO	dB	≥ 62
RF Parameters
Frequency Range	MHz	45~1000
Flatness in Band	dB	±0.5
Output Level	dBµV	≥ 80 (AGC: @-7~+1dBm)
Output Return Loss	dB	≥ 16
Output Impedance	Ω	75
Consumption	W	<1.2
Operating Temperature	°C	-20—+55
Dimension	mm	1048525
