we are the professional manufacturer of silent screw air compressor(15KW), and the our brand is SanLion which are sell well in home and abroad.
Many of the air compressor parts, such as the Rotor or Airend, filter, separator, are originally imported.
High quanlity as Germany standard, and favorable price.
The power range from 5.5KW(7.5HP) to 250KW(340HP).
Working pressure range from 5 Bar(72.5PSI) to 13Bar(188.5PSI).
The main characteristic of our screw air compressor as follows:
1. Our owned patent technology of Four-stage oil-gas dissociation system to secure the extremely low residual oil which is lower than 2PPM.
2. Originally imported from German ROTORCOMP or GHH-RAND air end or rotor to guarantee the reliablity and high efficiency.
3. Sensitive and reliable air intake controling system with originally imported check valve & butterfly inlet valve to prevent from stoping and vomitting oil.
4. Originally imported MANN+HUMMEL Air Filter, Oil Filter, and Oil-Air Separator to ensure the purity of oil and air, lowest loss of pressure, longer service time and maintenance interval.
5. DDR Multi-blade Centrifugal Fan with Higher efficiency, low power and noise, G2.5 vibration grade, high quality fan blade, ABB-tech for the motor with class-F insulation.
6. The fifth generation 2-line LCD digital intelligent control system of PLC with the protective function for oil less, high temperature and over-loading, maintenance reminder or prompting, RS485 messaging interface, meeted with several sets machine to work together.
7. EFF1 high performance special-made motor for screw air machine with Class-F insulation, SF coefficient up to 1.15, and SFK bearing with low noise, it will not burn down even if long-time over-loading.
The parameter of SK-20DS as follows:
Model |
Exhaust Pressure |
Air Displacement |
Motor Power |
Noise |
Interface |
Weight |
||||
Bar |
Kg/cm2 |
Psi |
cfm |
m3/min |
Kw |
HP |
dB(A) |
inch |
Kg |
|
Sk15 08DS |
8 |
8.2 |
116 |
56.5 |
1.6 |
11 |
15 |
60 |
G3/4 |
420 |
Sk15 10DS |
10 |
10.2 |
145 |
49.4 |
1.4 |
11 |
15 |
60 |
G3/4 |
420 |
Sk15 13DS |
13 |
13.2 |
189 |
40.6 |
1.15 |
11 |
15 |
60 |
G3/4 |
420 |
Sk20 08DS |
8 |
8.2 |
116 |
84.7 |
2.4 |
15 |
20 |
60 |
G3/4 |
450 |
Sk20 10DS |
10 |
10.2 |
145 |
70.6 |
2.0 |
15 |
20 |
60 |
G3/4 |
450 |
Sk20 13DS |
13 |
13.2 |
189 |
56.5 |
1.6 |
15 |
20 |
60 |
G3/4 |
450 |
