Air Drier(6.5m3/min)

Air Drier(6.5m3/min) thumbnail-1
Air Drier(6.5m3/min) photo-1
US$ 500 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Rotary Drying Equipment
Place of Origin:
Zhejiang, China
Brand Name:
Sanlion
Contact Supplier Request Quote Chat Now
Hangzhou Goldenlion Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Rotary Drying Equipment
Place of Origin Zhejiang, China
Brand Name Sanlion
Model Number ADH-60FJ

Sanlion low dew point refrigerant compressed air drier

Pressure: 8~~13Bar

Capacity: 0.8m3/min~~~45m3/min

Or as our customer required



On the easy principle of refrigeration, cool down the water vapor in the direct-heat saturated compressed air and eliminate the condensed liquid water. In this way, drier compressed air will be obtained to be used for production needs. Usually, dry compressed air with 3°C dew-point temperature is obtained by refrigeration drying.

1. Environmentally friendly refrigerant, high efficiency hermetic compressor and top brands of components.

2. More Compact Structure, Adopted with high-efficiency plate fin heat exchanger to achieve maximum heat exchanging efficiency. Maximum heat exchanging efficiency makes the product more smaller and saves space.

3. Lower pressure drop, less than 0.021MPA

4. Easier installation, Small size, easy to install. Modularized combination enhances production efficiency.

5. Fully automatic condensate drain valves for the lowest possible dew point under all rated design conditions - without freeze-ups

6. Creatively "built-in and exposed" automatic drainer for fast, reliable condensate removal and easily maintenance .



Parameter names

ADH-

10FJ

20FJ

30FJ

60FJ

75FJ

100FJ

120FJ

150FJ

200FJ

250FJ

300FJ

400FJ

Capacity

m3/min

1.5

2.6

3.8

6.5

8.5

11.7

13

17

23

27

34

45

Working pressure

Bar

2-10

Air Inlet Temp.

°C

≤85

Dew Point

°C

2-10

Compressor power

KW

0.28

0.6

0.75

1.1

1.3

1.5

2.2

2.9

3.7

4.8

5.5

7.5

Fan power

W

80

80

90

120

180

180

270

270

360

360

540

540

Interface

inch

ZG1

ZG1

ZG1

ZG1-1/2

ZG1-1/2

ZG2

ZG2

DN65

DN80

DN80

DN80

DN100

Length

mm

800

800

800

970

1100

1300

1550

1550

1550

1850

1850

1950

Width

mm

450

450

450

550

600

600

650

800

800

820

850

950

Profile

mm

710

710

710

800

870

870

1050

1200

1200

1280

1400

1430

Net Weight

Kg

80

85

90

180

200

250

285

380

460

550

650

750
