High Safety 150KW Vacuum Annealing Furnace With Stainless Steel Guide System

Name: High Safety 150KW Vacuum Annealing Furnace With Stainless Steel Guide System
Brand: HNHUI
SKU: 127532891
Availability: InStock

US$ 10,000 - 50,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, nitriding furnace

Usage:

Heat Treatment Furnace

Huzhou Hnhui Industrial Furnace Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, nitriding furnace

Usage Heat Treatment Furnace

Place of Origin Zhejiang, China

Brand Name HNHUI

Model Number vacuum annealing furnace

Voltage AC220/AC380/Others

Power(W) 150KW

Dimension(L*W*H) 2800 * 1250 * 900mm

Weight 2T-35T

Certification ISO9001

Warranty 1 Year

After-sales Service Provided No overseas service provided

Product Description

high safety 150KW vacuum annealing furnace with Stainless steel guide system
Device name	Horizontal vacuum annealing furnace without oxygen
use	Mainly suitable for copper pieces (coil, wire line) anaerobic annealing treatment.
Job dimensions	Effective material box:2800 * 1250 * 900 (mm)

The rated temperature	700 ℃; Commonly used working temperature: 650 ℃
Rated power	150KW
Heating element	Sealed radiation heating tube, outer tube material: Cr25Ni20;
Furnace protection gas	N2 (purity 99.99% or higher)
Vacuum	-0.1MPa,
The furnace gas circulation system	Stainless steel guide system, the high temperature sealing circulation fan;

Structure of equipment	Equipment by the tube furnace, furnace lining, furnace, radiation, the structure of the automatic charging car, furnace door, automatic door cover sealing device, automatic mechanical vacuum pump, vacuum valve, pneumatic system, circulation fan, fast cooling system, temperature control, temperature recording system of main parts, etc.In vacuum condition, the automatic filling the nitrogen protection, heat insulation, fast cooling. After this equipment treatment of workpiece surface oxidation, copper pieces of metal primary colors, the highest working temperature is 700 ℃.Through the intelligent temperature control table, touch screen and PLC automatic program control, dynamic process display, automatic conversion. Good system controllability, high safety performance, without manual operation.
