Introduction
Features of Cartoon Packing Machine
- This carton packing machine is adopted PLC programmable control, man-machine interface operation.
- All enclosed package.
- The automatic carton packing machine is automatic feeding, wrapping film, making bags, sealling cutting,the whole flat, shrink, packaging and finished product in whole complete.
- Constant temperature super alloy seal cutter, anti-adhesive,small sealing line , non-coking, non-smoke, zero pollution.
- When the cutting knife to the packing material will automatically rebound.
- Packaging size can be arbitrarily adjusted without changing mold
- Conveyor belt all the sets of PTFE insulated pipes, not hot, not harm the film.
- Shrink part adopts a dual circulating hot air chamber system, the temperature can be arbitrarily adjusted
- Conveyor motor adopts stepless variable speed motor, long life, low noise.
Samples of Cartoon Packing Machine
Specifications of Cartoon Packing Machine
BMD-450A
- Sealing type: L-sealing by means of L-bar
- Power supply: 380V/50-60Hz/3phase
- Packing capacity: 35 packs per minute (depends on product size and film width)
- L-bar size: 570x480 mm
- Max height of sealing frame: 125 mm
- Film type: center-folded film with 12-80 micron
- Max film size: width: 520mm (folded), outer diameter: 400mm
- Conveyor speed: 19 m/min
- Working height: 780-850 mm
- Rated power consumption: 1.2 kW
- Air pressure: <=0.5MPa (5 bar)
- PLC: Siemens CPU
- Sealing system: permanently heated seal bar with easy-exchangeable sealing blade with Teflon, temperature controlled and detected by PLC
- Operating interface: Touchscreen Eview MV506, display operation guidance and error diagnostic
- Machine material: stainless steel
- Machine dimension: 1600x770x1450mm
BMD-450B
- - Power supply: 380V/50-60Hz/3phase
- - Oven size: 1200(length) x 450(width) x 220(height) mm
- - Conveyor speed: variable, 40 m/min
- - Conveyor: chains with rotating silicon coated rods
- - Temperature control: By electronic thermostat
- - Rated power consumption: max 7 kW
- - Working height: 780-850 mm
- - Machine material: stainless steel
- - Machine dimension: 1600x600x1260mm
Shrinking Equipment Details of Cartoon Packing Machine
Standard export packing for Cartoon Packing Machine
1.Cover by PVC film + fumigated wooden case;
2.Wooden case suitable for long distance ocean shipping.
Dongtai has a highly sophisticated technical talent, has a high-quality team, can in a timely manner to provide cusotmers with comprehensive after-sale service.
No damage to human factors, all products one year warranty, life-long maintenance.
JINAN DONGTAI MACHINERY MANUFACTURING CO., LTD. is a professional packaging machinery manufacturer. For many years, we have devoted great efforts on researching and developing products under DONGTAI & XUNJIE brand, making remarkable quality, especially in filling machine and packaging machine.
Now we have been one of the biggest manufacturer of packing machine in northeast of China, and exported our products to 21 countries, such as USA, Holand, AE, Canada, Brazil, Russia, Austrilia, India and so on.On the basis of excellent quality and competitive price, you will be surely get a big success in your industry.
Jinan Dongtai Workshop
Other Products
Various packaging machine, packaging related machinery, packing machine, semi-auto filling machine, automatic liquid filling machine, antifreeze filler, paste lotion filler, magnetic pump manual liquid filling machine, coding machine, sealing machine, electromagnetic induction sealing machine, labeling machine, shrinking machine, granule packing machine, powder packing and filling machine, vacuum packaging machine, etc.
Filling Line
Technology Certification
CE Certification and ISO9001 Certification
Warm Reminder of Transaction Process
After the both sides reached cooperation intention, the transaction process as the following:
Signed the contract -to pay down payment through customer service - factory arranged production before testing - detection Before shipment - delivery - the client received and pay final payment
Manufacturing Process
For the Reason about why Choose Our Machinery Equipment
We as a manufacturer are specialized in all kinds of packaging machinery equipment.
Good experience of many years and to be devoted to the packaging industry for food, medicine, daily chemical, washing, beverage and other industries packaging, etc.
Provide best price&fast delivery
Manual&automatic status switching function
Operating&cleaning conveniently
Good experience of OEM&ODM for our customers
High accuracy; stable system; can be adjustable and customized;
To be suitable for various sizes, wide varieties etc.
Our machinery could save time, resource and let peple confidently used it.
Our business involves various markets all over the world, in many fields with our excellent product performance.
When you send inquiry,please also included the capacity and bottles shape you need to work on the machine, it is easy and accurately for us to recommand a right machine! If any special,our manufacture also can design the machines according your requirement.
