Cummins power genset 200kw/250kVA (NCC250)
USD $3,000 - $12,000
/ Set
1 Set(Min.Order)
- 200 Set / Sets per Month
- yanttian
- T/T D/P D/A
You May Like
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | NANCHAI | Model Number: | NCC250 |
| Output Type: | AC Three Phase | Speed: | 1500/1800rmd | Frequency: | 50/60Hz |
| Rated Power: | 200kw | Rated Voltage: | 380/400/440/480v | Rated Current: | 360A |
Product Description
Specifications
1. 6LTAA8.9-G22 .Fuel Consuption: 207g/kw.h
3. Dispalcement: 8.3L
4. CE certificate
5. ISO9001:2008
| Generator Type | Open Type |
| Genrator Set Model | NCC250 |
| Capacity(KVA/KW) | 200/250 |
| Rated Current(A) | 360 |
| Fuel Consumption(g/kw.h) | 207 |
| Engine Brand | Cummins |
| Engine Model | 6LTAA8.9-G2 |
| Alternator | MP-200-4 |
| Controller | DSE4620 |
| Speed(RPM) | 1500/1800 |
| Cylinder Quantity | 6 |
| Cylinder Type | L |
| Cylinder Bore(mm) | 114 |
| Cylinder Stroke(mm) | 145 |
| Air inspiration | natual |
| Speed Governor | electronic AVR |
| Start system(VDC) | 24 |
| Weight(Kg) | 2500 |
| Size(L*W*H)(mm) | 2600*970*1500 |
| Lubricant Class | 15W40-CF4 |
| Output Voltage(VAC) | 415/240 380/220 400/230 480/277 |
| Output Frequency (Hz) | 50/60 |
| Phase | 3P 4wires |
| Lagging Power Factor(%) | 0.8 |
| Internal protection | IP22 |
| Voltage Tolerance(+/- %) | 1 |
| Insulation Class | H |
