Meanwell 5.5W 10v 550ma Led Dimmable Driver With CE & ROHS
US$ 0.3 - 8.6
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM/ ODM/ FEKKO
Model Number:
SAW005100550
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
24W 12V 2A Waterproof LED Driver IP67 for LED Light FCC, CE, ROHS CertificatesNegotiableMOQ: 200 Pieces -
30W 12V Waterproof LED Light DriverNegotiableMOQ: 200 Pieces
-
12V 8A LED Driver Power Supply With Waterproof OutdoorNegotiableMOQ: 200 Pieces
-
30W Constant Current LED DriverNegotiableMOQ: 100 Pieces
-
FK-L230-60W Select Voltage LED DriverNegotiableMOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
OEM/ ODM/ FEKKO
Model Number
SAW005100550
Output Type
DC
Connection
Plug In
meanwell 5.5W 10v 550ma led dimmable driver with CE & ROHS
product specification
Input:
- Voltage Range: 90~264VAc
- Frequency Range: 47~63Hz
- Efficency: >85%
- AC current (max): 1.1A @ 220V, 2.0A @ 115V
- AC Inrush Current: 40A @ 230V
Output:
- DC Voltage: 10V +/- 2%
- Rated Current: 0.55A
- Rated Power: 5.5W
- Ripple & Noise (max): mVp-p < 1% Uout
- Load Regulation: +/- 1%
- Setup Time: 500ms
- Rise Time: 20ms
- Hold UP Time: 30ms @ 230V, 10ms @ 115V
Protection:
- Short Circuit Protection
- Overload Protection: 130~150%
- Over Voltage Protection: 115~135%
Environment:
- Working Temperature: -20~50C
- Working Humidity: 20%~90% RH
- Storage Temperature: -40~60C
- Storage Humidity: 20%~95% RH
Safety Compliance:
- Safety Standard: meet CE, FCC, GB4943
- Withstand Voltage: IP/OP 5mA 2KVAc
- Isolation Resistance: IP/OP 100M Ohms
Waterproof Rank:
- Waterproof Rank: > IP67
Size:
- Dimension: 191*46*35mm
- Weight: 126gram
Protection:
Short circuit protection,
Over voltage protection,
Over current protection,
Thermal shutdown capability.
Our factory:
5,000 square meters
150 well-trained staffs
18 R&D engineers
18 QC auditors
4 SMD workshops, equipments imported from Japan
2 semi-automated production lines
500K/M current monthly capacity
ISO9002 quality assurance
UL/CUL , CE, FCC, CCC, KC, GS, TUV , C-TICK , SAA,CB, ROHS approvals , 6 level efficiency .
Our principle: Lowest price and GOOD quality.
