Help CenterFK-L230-60W Select Voltage LED Driver
Related Products
-
150W LED Driver Select VoltageNegotiableMOQ: 100 Pieces -
Waterproof 12V/12.5A 150W LED Driver IP67 Constant CurrentNegotiableMOQ: 100 Pieces
-
I67 Waterproof 120W LED Driver With Constant CurrentNegotiableMOQ: 100 Pieces
-
FK-L093-100W LED Driver Select VoltageNegotiableMOQ: 100 Pieces
-
FK-L092-100W LED DriverNegotiableMOQ: 100 Pieces
Features
Input 175V-265V
Select Voltage 12V to 48V/isolation
(Power 60W)
waterproof IP67
* Universal AC input/Full rang;
* Protections;Short circuit/Over load/Over voltage/Over temp;
* Built-in active PFC function,PF>0.96;
* IP67/IP65 design for indoor or outdoor installations;
* OCP point adjustable through output cable or internal
potential meter;
* Cooling by free air convection;
* Suitable for all kinds of LED lighting,street lighting,and
moving sign applications;
* Built-in constant current limiting circuit (C.C.+C.V.mode);
* Meet 4KV surge immunity level (IEC6100-4-5);
* 3 Years warranty;
Technical data
Input Voltage Range:85-305VAC
Power Factor:typical 0.96
THD:<10%
Power Efficiency:91%-94%
Output Voltage:12-105VDC
Output Current:1.42A-11.0A
Environmental specification/EMC
Operation temp:-40-70°C(refer to output derating curve)
Storage temp:-40-85°C
Humidity:10-90%RH
MTBF calculation:Up to 50,000 Hours Lifetime
Safety approval:Meet UL8750(UL60950),EN61347,CCC
EMC standards:CISPR15; FCC 47CFR-Part15B
Our factory:
5,000 square meters
150 well-trained staffs
18 R&D engineers
18 QC auditors
4 SMD workshops, equipments imported from Japan
2 semi-automated production lines
500K/M current monthly capacity
ISO9002 quality assurance
UL/CUL , CE, FCC, CCC, KC, GS, TUV , C-TICK , SAA,CB, ROHS approvals , 6 level efficiency .
Our principle: Lowest price and GOOD quality.
