plastic coated air conditioner duct for wholesale air conditioners, air conditioner parts outdoor unit
410 air conditioner pipe fittings is with 15cm long copper cap and PE heat shrinkable tube
Mechanical Properties of air conditioner tube
- The length of pipe, copper head and wall thickness of pipe can be customized.
- Advance cutting machine promote precision degree.
- Pure copper matrial with good stretching resistance, content of copper reaches 99.9%.
- 100% cleanliness with no residue inside.
- No defects on the surface of air conditioner tube during production.
- Extruded and Closed cell white polyethylene with a white outside PE-protection layer;
- Average Density: 33Kg/m3;
- Heating Conduction at 00≤0.033W/MK;C
- Working Temperature from -400C until +1200C;
- Vapor Resistance: μ>5000;
- White external non toxic and resistance to external chemical agents and ultra-violate rays;
- RoHS Certificate Approved;
| Spec.(inch) |
Metal tube outer dia.*wall thickness(mm) |
Insilating thickness(mm) | Length(m) | Quantity per carton |
|---|---|---|---|---|
| 1/4" | 6*0.7 | 7/9 | 2-15 | 5 |
| 3/8 | 9.52*0.7 | 7/9 | 2-15 | 5 |
| 1/2 | 12*0.8 | 7/9 | 2-15 | 5 |
| 5/8" | 15.88*0.9 | 7/9 | 2-15 | 5 |
| 3/4" | 19.05*1.2 | 7/9 | 2-15 | 5 |
| Items | Test method | Result |
| Airtightness property | 4.0MPA, 5 min | No leak |
| Presure resistance | 12MPA, 1 min | No crackle |
| Bendability | Diameter 180 deg | No pleat and crackle |
Nylon bage or hard paper carton. Or as customer's request.
1 The length of pipe, copper cap and wall thickness of air conditioner tube can be customized.
2 Short delivery time, 3-7 working days.
3 Free sample of air conditioner tube can be available.
4 Professional engineer with six year experience to solve your problem regarding air conditioner tube.
5 Excellent afer sale severce, 100% compensation if any quality problem.
6 Small order about air conditioner tube is also welcomed.
Dongguang YiDu Refrigeration Technology Co.,Ltd was established in 2009, specializing in the RD and manufacture of refrigeration accessories,especially the cooper/aluminum connecting pipe for air conditioner. Product arrange includes the central air-conditioner heat preservation copper tube, air-conditioning aluminum tube, air-conditioner coating tube. Due to innovative improve technology, YiDu can ensures 4 mian advantages compared with other competitors. A First class cutting machine would not hurt pipes, avoiding narrowing size, leakage or water drop. B Excellent welder with gas bar, makes sure the inside of pipe completely empty, no occlusion, meanwhile keep original size. C 100% no aluminum slag. D OEM service, the length and wall thickness of airconditioning pipe or insulation pipe can be customized. For six years,YiDu has already built a well-earned reputation for producing the finest products with reasonable cost. Manufacture capacity can reach 4k-6k sets daily. Products have been exported to Europe, America, Japan, Middle East, Southeast Asia,and so on. Welcome to contact our sales for quotation.
