Help CenterLevel Switch Stainless Material
US$ 4.7 - 5.3
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Erlang
Model Number:
SFS-1A-90
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Horizontal Type Level SensorUS$ 1.9 - 2.2MOQ: 200 Pieces -
Small Float Switch for DehumidifierUS$ 1 - 1.5MOQ: 500 Pieces
-
Water Float Switch Stainless Steel MaterialUS$ 4.5 - 4.8MOQ: 1000 Pieces
-
Water Float Level SensorUS$ 1.2 - 3.4MOQ: 500 Pieces
-
PP Material Water Level SensorUS$ 1 - 4.5MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
Erlang
Model Number
SFS-1A-90
Usage
Other, level switch
Theory
Other, current switch
Output
Switching Transducer
level switch
Movement Explaination:
A float switch is a device used to sense the level of liquid in a tank.
When the float ball of the level switch rises or falls with the liquid. The magenetic force of magnet
which inside of the float ball will cause the reed switch to turn on. When the float ball move away
from the reed switch, the reed switch will turn off.
Application:
water heater, water dispenser, air-condition, BSD-P, humidifier, dehumidifier,fluid control,a pump,an indicator,an alarm,or other device.
If there is no product suitable for your desire,you can also send some data and pattern of your product that you desired ,our company will design it for you particularly!
Our products has been authenticated by ISO9001.
| Data Scan | SFS |
| Max Contact Rating | 10W |
| Max Switching Voltage | 100VDC |
| Max Switching Current | 0.5A |
| Min Breakdown Voltage | 250VDC |
| Max Carry Current | 1.0A |
| Max Contact Resistance | 100mΩ |
| Temperature Rating | -30~85°C |
| Float Ball Material | PP |
| Float Body Material | PP |
| Hexagon Nut Material | PP |
