Home > Products > TIG INVERTER WELDER--GTAW > TIG WSE INVERTER WELDING MACHINE
TIG WSE INVERTER WELDING MACHINE
- 6000 Set / Sets per Month
- Ningbo/Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | eDON | Model Number | WSE-200/315 | |
| Arc Current | 10-200 | Pulse Frequency | 50/60Hz | |
| Rated Duty Cycle | 60% | Dimensions | 590*345*485 | |
| Usage | welding mild steel,stainless steel,alloyed steel,copper | Warranty | 1 year |
Product Description
Specifications
1. Stable ARC AC/DC TIG INVERTER WELDING MACHINErc, beautiful welding surface and easy operation.2. Light and low noise.
1. Stable arc AC/DC TIG INVERTER WELDING MACHINE, beautiful welding surface and easy operation.
2. Light and low noise.
3. Be able to weld mild steel, S/S, copper and titanium etc by DC function.
4. Be able to weld aluminum and aluminum alloy by AC function.
ITEM |
WSE-200 |
WSE-315 |
Voltage/frequency | AC220V±10%50Hz/60Hz | AC380V±10%50Hz/60Hz |
Rate input capacity(KVA) | 4.5 | 8.9 |
Output current range(A) | 20-200 | 25-315 |
Duty cycle(%) | 60 | 60 |
Output voltage(V) | 18 | 23 |
No-load voltage(V) | 56 | 45 |
Arc starting | HF | HF |
Efficiency(%) | 85 | 85 |
Power factor(COS) | 0.93 | 0.93 |
Pre-flow(S) | 0-5 | 0-5 |
Blowing time(S) | 0-2 | 0-2 |
Down-slope time(S) | 0-5 | 0-5 |
Pulse duty factor(%) | 20-80 | 20-80 |
Attenuation time(S) | 0-5 | 0-5 |
Exhaust time(S) | 2-10 | 2-10 |
Net weight(kg) | 24 | 39 |
Cross weight(kg) | 28 | 44 |
Protection class | IP21 | IP21 |
Insulation class | B | B |
Dimension(mm) | 580*334*480 | 580*334*480 |
