TIG Inverter Welding Machine
- Ningbo/Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | eDON | |
| Model Number | TIGa-160/180/200/250 | Arc Current | 10-200 | |
| Pulse Frequency | 50/60Hz | Rated Duty Cycle | 60% | |
| Dimensions | 371*155*295 | Usage | welding mild steel,stainless steel,low alloyed steel,copper |
Product Description
Pass ISO9001 system and gain CCC,CE certificate.
Application:
Pipe welding,thin sheet fabrication,
special materials such as titanium,installation,repair,maintenance
Accessories:
TIG torch,earth clamp,welding cable,brush/hammer,protective mask
parameter:
ITEM |
TIGa-160 |
TIGa-180 |
TIGa-200 |
TIGa-250 |
Voltage/frequency | AC220V±10%50Hz/60Hz | AC220V±10%50Hz/60Hz | AC220V±10%50Hz/60Hz | AC380V±10%50Hz/60Hz |
Rate input capacity(KVA) | 3.3 | 3.9 | 4.6 | 6.3 |
Output current range(A) | 10-160 | 10-180 | 10-200 | 20-250 |
Duty cycle(%) | 60 | 60 | 60 | 60 |
Output voltage(V) | 16.4 | 17.2 | 18 | 20 |
No-load voltage(V) | 42 | 42 | 42 | 54 |
Arc starting | HF | HF | HF | HF |
Efficiency(%) | 85 | 85 | 85 | 85 |
Power factor(COS) | 0.93 | 0.93 | 0.93 | 0.93 |
Blowing time(S) | 2 | 2 | 2 | 2 |
Net weight(kg) | 8 | 8 | 8 | 22 |
Cross weight(kg) | 12 | 12 | 12 | 26 |
Protection class | IP21 | IP21 | IP21 | IP21 |
Insulation class | B | B | B | B |
Dimension(mm) | 371*155*295 | 371*155*295 | 371*155*295 | 480*205*355 |
