Hydraulic Hose Crimping Tool/bending Machine /curving Machine

Hydraulic Hose Crimping Tool/bending Machine /curving Machine thumbnail-1
Hydraulic Hose Crimping Tool/bending Machine /curving Machine photo-1
US$ 10,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
willing
Contact Supplier Request Quote Chat Now
Hangzhou Willing International Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name willing
Machine Type Roller-Bending Machine
Raw Material Sheet / Plate Rolling
Material / Metal Processed Carbon Steel
Power Hydraulic
Automation Automatic
Extra Services Other
Certification CE

Specifications

hydraulic hose crimping machine

hydraulic hose crimping tool/bending machine /curving machine



Material Spec            Color steel sheet;

thickness of material   0.4-0.6mm

coil width             1000mm

Coil stress               235Mpa

Main motor power       5.5kw

hydraulic station power   3kw

Working Speed         10 ~ 12 m/min.

Cutting Tolerance       ≤±2.5mm ( length≤ 5000mm)

≤±3mm ( 5000mm < length ≤ 10000mm)

Type of cutting           Roll-formed and length-set cutting

Voltage               380V 3 phase 60Hz



Material of Main Equipment

Roller Material High grade No.45 forged steel, with digital-controlled procession,

                 plated 0.05mm on one side with hard chrome.

Active Shaft Material High grade No.45 carbon wrought steel,which can improve the integrated mechanic feature of the shaft Φ75mm.

Electric Elements       PLC control panel, transducer imported from Mitsubishi of Japan.

Other elements from famous suppliers in China

Cutter blade             Cr12 mould steel with quenched treatment



Working Flow

Decoiling the sheet       Sheet guiding    Roll forming      Measure length

Cutting the panel    panels to the supporter

Standard Equipment of Machine

Guiding Equipment                   1set

Precutting                                    1set

Roll Forming Equipment          1set

Post Cut Equipment                 1set

Hydraulic Station                       1pc

PLC Control Panel                   1pc

Supporter Table                       2pcs
