filling machine for juice,tea etc hot filling line
1, Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2, Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted.
3,Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4, High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment throughly.
5, splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel ,within ten minutes.
2, Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted.
3,Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4, High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment throughly.
5, splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel ,within ten minutes.
canned beverage capper machine.
1.Filling machine
2.Beverage machine
3.Water liquid Filling machine
4.Safty
5.Washing Filling and Screw Capping
The Washing Filling and Screw Capping is a full-automatic multiple-funcition washing, filling and capping unit. It is used in washing, filling and sealing all kinds of no gas contained liquid, such as fruit jujice, oil &vingar, wine, fruit wine, mineral water and pure water.
The washing filling and screw capping line has features of unique design, new stytle, complete fuctions, multipurpose, convenient in operation, beautiful construction, high automaticity. The Washing Filling and Screw Capping is the best filling equipment in China.
| Model | CGF16126 | CGF18186 | CGF24248 | CGF323210 | CGF404012 | CGF505012 | CGF606015 | CGF808020 |
| Heads of washing, filling, sealing | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 | 50-50-12 | 60-60-15 | 80-80-20 |
| Production capacity(bottle/hour) (600ml) | 2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-20000 | 20000-24000 | 25000-30000 | 35000-40000 |
| Suitable bottle diameter(mm) | φ=50-110 =170 330-2250ml | |||||||
| Spraying pressure | 2~3 | |||||||
| Motor power | 2.2kw (Main motor) | 2.2kw(Main motor) | 3kw (Main motor) | 5.5kw (Main motor) | 7.5kw(Main motor) | 11kw(Main motor) | 15kw(Main motor) | 19kw(Main motor) |
| Overall dimension(L*W*H) (mm) | 2400*1650*2500 | 2600* 1920*2550 | 3100*2300*2800 | 3800*2800*2900 | 4600*2800*2900 | 5450*3300*2900 | 6500*4500*2900 | 76800*66400*2850 |
| Weight(kg) | 2500 | 3500 | 4500 | 6500 | 8500 | 9800 | ||
