Home > Products > PSA Oxygen /Nitrogen Plant > Psa Nitrogen Machine
Psa Nitrogen Machine
- 20 Unit / Units per Month
- Shanghai
- T/T
Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | HANG TONG PSA Nitrogen Machine |
Model Number: | BF- 80 | Usage: | Nitrogen | Production Rate: | 100% |
Voltage: | 380v/220v | Certification: | ISO, GB, ASME | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
PSA Nitrogen Machine1) Output: 80Nm3/h
2) Purity: 90~99.99%
3) Delivery:60 days
4)ASME,ISO,GB standar
PSA Nitrogen Machine
Part 1.Main descriptions of VPSA Nitrogen plant
1).This plant selectively absorbs the nitrogen in the air by the utilization of molecular sieve, which can absorb and desorb nitrogen according to working pressure. With the air being separated, high purity oxygen can be obtained.
Process Flow:
This set of PSA oxygen generating system mainly consists of air compression, air purification and PSA oxygen production
(1) Air compression: Air is compressed by the air compressor to 0.7-0.8Mpa, which provides continuous and steady air flow and pressure for the oxygen generating system.
(2) Air purification: Compressed air goes through refrigerated air dryer and filter in order to remove water, oil and dust, which prepares to provide the clean air source for the next step PSA.
(3) PSA oxygen production: Purified air goes into the two adsorption towers of PSA oxygen generator after decompression. The loading molecular sieve in the adsorption tower will adsorb the oxygen and set it free. The pure oxygen will go into the next step storage tank.
2).Main parameters
Model |
Nitrogen Output Nm³/h
| Nitrogen Purity % | Product Pressure (MPa) | Total Power KW | Area M² |
BF-5 | 5 |
90.0% ~ 99.99% |
≥ 0.6 | ~10 | 1.5 x 1.5 |
BF-10 | 15 | ~15 | 2.0 x 1.5 | ||
BF-20 | 20 | ~22 | 2.3 x 1.8 | ||
BF-30 | 30 | ~22 | 2.5 x 2.0 | ||
BF-50 | 50 | ~37 | 3.0 x 2.5 | ||
BF-80 | 80 |
90.0% ~ 99.5% | ~45 | 3.0 x 3.0 | |
BF-100 | 100 | ~55 | 5.0 x 4.5 | ||
BF-200 | 200 | ~95 | 5.0 x 5.0 | ||
BF-400 | 400 | ~170 | 5.0 x 5.0 | ||
BF-500 | 500 | ~220 | 6.0 x 5.0 | ||
BF-600 | 600 | ~260 | 8.0 x 7.0 | ||
BF-800 | 800 | ~280 | 8.0 x 10.0 | ||
BF-1000 | 1000 | ~315 | 10.0 x 10.0 | ||
BF-1500 | 1500 | ~540 | 14.0 x 16.0 |
Part 2.Main Applications And Advantages
The VPSA oxygen generating is widely used in every field, such as steelmaking, glass smelting, pulp bleaching & paper making, sewage treatment, nonferrous metal smelting, petrochemical engineering, mineral processing, aquiculture, fermentation and drinking water treatment, etc.
Compared to large-sized air separation plants, VPSA is featured with less investing capital, energy-saving, less area, stable property, simple operations, and high level of automation.The purity of oxygen, and nitrogen is up to 93% and 99.99%.The plants are designed flexibly, since it can be made according to different requirements and applications.
Part 4. About Our Company and Certificates
Our company has obtained the A2 and C2, C3 Pressure Vessel Fabrication Certificates ,Grade GC1 Pressure Pipe& Vessel Construction Certificates, ISO9001 Quality Certificate, ASME Certificate and U Stamp.
We specialize in producing air separation plants, CO2 recovery plants with or without source gas, cryogenic liquid storage tanks (LO2, LN2, LAr, LCO2, LNG and LPG), ISO tanks, semi-trailer tankers, vaporizers, gas filling stations, cylinders and dewars, dry ice machines, compressors and cryogenic pumps etc. Pls feel free to contact us for further information, we are here ready for you!
Part 5. Why Choose Our Company
1) Our team is highly qualified and experienced;
2) We focus on providing excellent quality products;
3) Our products is energy-saving and environment-friendly;
4) Our price is reasonable and competitive based on the same quality level;
5) Excellent after-sale service.
