Hot Selling Good Performance Gas Vaporizer

Part 1 Main introdution

The vaporizer is a kind of industrial gas equipment. Our company offers two types of it: 20-10000m³/h ambient air series and 500-100000m³/h water bath series. The installation, removal and operation are quite easy.

The ambient air vaporizer makes use of natural air convection to heat the cryogenic liquid, making it completely evaporate into gas. It is highly efficient heat exchange equipment that integrates both air exchange and heating features. This evaporator serves as an energy-efficient alternative to heating vaporization devices. It has thickened and strengthened fins, increasing the heat transfer area without the need for additional energy. It is our recommended product.

The water bath vaporizer adopts a heat exchange between hot water and cryogenic liquid gas, thus enabling gasification of cryogenic liquid gas. It features compact structure and small footprint. It is also easy to transport and operate.

Suitable medium: liquid oxygen, liquid nitrogen, liquid carbon dioxide, liquid argon, liquid natural gas, liquid petroleum gas, liquid ethylene, liquid ammonia, etc.

Part 2 Product specification

Product specification: Air Heated Vaporizer

Product model:QQ-150/40

General technical parameters:

1,Capacity:                                              150Nm³/h

2,Max Outlet Pressure:                              40bar

3,Medium:                                                  LO_2,LN2,LAr

4,Externality dimension:                      1710*1056*2050mm

5,Weight:                                               ~660kg

6,design temp:                                            -196°C

7,Main material:                                    0Cr18Ni9 and LF21

Model List and Technical Parameters

Part 3 Purchasing Guide

We can offer vaporizers in customized sizes. Please advise the following when sending an enquiry:
1. flow rate
2. medium gas
3. inlet pressure
4. outlet pressure

1) Capacity (Nm³/h): 100, 200, 400, 800, 1,000, 1,500, 2,000, 2,500, 5,000, 10,000, 20,000

2) Heat-exchange area (m²): 38, 77, 146, 292, 365, 547, 730, 819, 1640, 3,280, 6,560
3) Net weight (kg): 168, 327, 629, 1,245, 1,556, 2,738, 3,160, 3,600, 7,200, 14,400, 28,800
