Help CenterChinese Supplier High Purity Niobium Foil Price for Sale
Related Products
-
Hot Sale High Quality Niobium Bar for Steeling MakingUS$ 228 - 248MOQ: 5 Kilograms -
99.95% Pure Niobium Screw With Nuts Washer Corrosion Resistance for IndustryUS$ 8 - 20MOQ: 10 Pieces
-
Dependable Performance Annealed Niobium Bars RodsUS$ 228 - 248MOQ: 5 Kilograms
-
99.95% Niobium Bar PriceUS$ 150 - 300MOQ: 5 Kilograms
-
ZHIPU Brand Niobium Sputtering Target With High QualityUS$ 20 - 200MOQ: 1 Piece
Specifications
Niobium Sheet (cold rolled, annealed)Thickness: 0.5 mm to 50 mm
Width and length: 1000 x 2000 mm or as your request
niobium foil
1.Good thermal stability.
2.High quality, workability titanium surgical screws
3..Timely delivery as your requirements.
1. Grade: Nb1, Nb2
2. Purity : >=99.95%
3. Characteristic:
Melting Point: 2468 Degrees Celsius
Boiling Point:4742 Degrees Celsius
Density: 8.57 g/cm3
Standard:ASTM B393-98
Shape: foil shape
Min thickness: 0.03mm
Surface: bright and smooth
Color: silver
Dimensions: THK 0.03-1.0mm* W5-100mm
4. Certificate: ISO9002
5. Product Feature: cutting plotter foil
a. High melting point, Melting point: 2468 °C, Boiling point: 4742°C
b. Low vapor pressure
c. Good cold processability
d. Excellent chemical stability
e. Good resistance to corrosion
f. High dielectric constant,in surface oxide film
6. Dimensions and tolerance(According to clients’ requirements):
Chemistry % | ||||||||||||
Designation |
Chief component |
Impurities maxmium |
||||||||||
Nb |
Fe |
Si |
Ni |
W |
Mo |
Ti |
Ta |
O |
C |
H |
N |
|
Nb1 |
Remainder |
0.004 |
0.003 |
0.002 |
0.004 |
0.004 |
0.002 |
0.07 |
0.015 |
0.004 |
0.0015 |
0.002 |
Nb2 |
Remainder |
0.02 |
0.02 |
0.005 |
0.02 |
0.02 |
0.005 |
0.15 |
0.03 |
0.01 |
0.0015 |
0.01 |
7. Application:
widely used in many industries such as electronics, metallurgy, chemical processing, hard alloy cutter, aerospace and aviation.
Package details
First, packaging with moisture-proof paper
Second, packaging with kraft paper
Third, packaging with foam plastics in all side of plywood case.
Finally packing products in plywood case
Company information
Baoji Zhipu Non-Ferrous Metals Processing Co.,Ltd. Was established in the beginning of 2002. Through 12 years of development, our company is concentrating on deep processing of new material, especially on hard-to-be- melt metal material. The tungsten, molybdenum, tantalunm, niobium, zirconium and titanium are made as raw materials for development, production and fabrication.
The company mainly products: the billets, plates, sheets, foils, discs, bars, wires, tubes, cakes, rings, target, electrode, crucible and other downstream products of tungsten, molybdenum, tantalum , niobium, zirconium, titanium, nickel and other rare metals materials. With professional technological development and manufacturing ability, we devoted to refractory metals downstream products.
Contact information
Tel:86-0917-3605643
Fax:86-0917-3602511
TM:cn1510696876
Hope you have a great day
