Home > Computer Products > Network Hardware & Parts > Router > Mini Smart 3g Portable Network Wireless Wifi Router

Mini Smart 3g Portable Network Wireless Wifi Router

Name: Mini Smart 3g Portable Network Wireless Wifi Router
Brand: FLKL
SKU: 127311845

US$ 18.5 - 21 MOQ: 10 Pieces

Key Specifications

Products Status:

Stock

Type:

Wireless

Application:

Other, Soho,House,Office,Hotel,etc.

Xiamen KaiJ Lighting Electrical Appliance Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Wireless

Application Other, Soho,House,Office,Hotel,etc.

Function Firewall, QoS, VPN

LAN Ports 8

WAN Ports 1

Certification CCC, CE, IEC,CQC

Brand Name FLKL

Model Number FL-WF01

Place of Origin Fujian, China

Product Description

Mini smart 3g portable Network wireless wifi router

Main Chipset		MT7620A
RAM		DDR2 128MB (MAX DDR2 256MB)
SPI FLASH		16MB (MAX 16MB)
Protocol		IEEE 802.11n,IEEE 802.11g,IEEE 802.11b,IEEE802.11ac ,IEEE802.11a IEEE 802.3,IEEE 802.3u
RT Power		802.11b 18dBm±2dBm; 802.11g 15dBm±2dBm; 802.11n 15dBm±2dBm; 802.11ac depends on the 11AC mode;
Reception Sensitivity		802.11b: -83dBm@10% PER 802.11g: -74dBm@10% PER 802.11n: -68dBm@10% PER 802.11ac: depends on the 11AC mode;
Work Channel		2.4GHz choose :1-13 5GHz choose :149,153,157,161,165
Wireless Rate		Max 1200Mbps(depends on the 11AC mode)
Work Frequency		2.4GHz,5.8GHz

Interface		USB card slot 1 10/100/100M WAN port(Auto MDI/MDIX) 1 10/100/100M LAN port(Auto MDI/MDIX)
LED		Power,PCIE mode ,2.4G,WAN,LAN1,LAN2,LAN3,LAN4
Button		Reset/WPS
Max Power consumption		< 12W
Dimension(LWH)		1418526MM

Software
WAN Type	PPPoE,Dynamic IP, Static IP
Work Mode	AP; Router;
DHCP	Server, Client, DHCP Client List, Address Reservation
Port Forwarding	Virtual Server, Port Triggering, UPnP, DMZ
Firewall Security	Dos, SPI Firewall IP Address Filter/MAC Address Filter/ Domain Filter IP and MAC Address Binding
DDNS	Support
VPN Pass-Through	PPTP, L2TP, IPSec (ESP Head)
Band Ctrl	Support
Static Router	Support
System Log	Support
Other Function	Mac clone NTP Synchronize Web firmware upgrade

Others
Work Environments	Operating Temperature:0℃ ~ 40℃; Storage Temperature:-40℃~ 70℃; Operating Humidity:10%~90% non-condensing Storage Humidity:10%~90% non-condensing
Adapter	12V 1A
