FRP High Quality SMC Door Skin mould
SMC Mould
Moulds are produced from High grade steel and with hardening HRC 48-52.
Beryllium bronsze applied in the punch & Cavity to make the cooling more efficiently.
Moulds were designed for fully automatic production, off-tool parts.
1. Mouldbase
Standardization Use, whenever possible metric standards like LKM for all the mould components. (including guide bushing, guide pin, ejector pin and so on.)
2. Moudbase surface finishing
All plates should be painted with automotive paint blue or green to protect against the corrosion.
3. Cores & cavities
The cores, cavities and inserts made of stainless steel, hardened and tempered up to 45-48 HRC.
Surface finish: Mirror Finish-Diamond Polished.
4. Core wedge blocks
To be manufactured from P20 local steel and heat treatment by gas nitriding.
Wedge blocks need to be located in deep pockets to prevent movement.
5. Steel hardness in general
It is good practice and necessary to have a difference of several points HRC hardness between
sliding steel mould parts to prevent pick up between the steel parts. For example any P20 core slides
or wear plates should be gas nitride.
(Steel material and final hardness certificate will be supplied with the molds.)
The following is mould information for your reference:
SMC Mould Specification Sheet | |
Item |
Description |
Mould Material |
C45, P20, 718, 2738, Nak80, S-7 etc. |
Mould Base |
LKM, HASCO, |
Standard Mould Parts |
DME, HASCODME, HASCO |
Cavity |
Single / Multiple |
Mould Life |
1,000,000 shots and up |
Plastic material |
PP, ABS, HDPE, PC, PVC ect |
Design Software |
UG, PROE, Cimatron, Solidwork ect |
Delivery Time |
20-45 days |
Payment |
By T/T |
Besco Machinery Limited is professional on manufacturing mechanical power press, pneumatic power press, hydraulic press, press brake, shearing machine, plate bending and rolling machine, profile bending and rolling machines, cut to length and slitting line, etc.
We have 18 years experience on manufacture metal working machines and we export our machines to all the worldwide market and have the best response from customers.
We will offer you our best quality machine and the after sale service.
1. Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer’s country if you want, and the buyer must take charge of all the expenditure including airplane tickets of our engineers when in the buyer’s country to do the service!
2. Warranty period is1 year. During the warranty period we shall reply to the call or Fax from the user for the machine faults (expect for faults caused by no abiding by the relevant operation regulations, or by force injury) within 24 hours.
Question1: What is about the payment?
Answer:Payment:30% T/T as advance, 70% T/T before delivery.
Question2: what is about the delivery time?
Answer:That depend on the stocks.
