Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord thumbnail-3

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord photo-1

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord photo-2

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord photo-3

US$ 1 - 5 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

Contact Supplier Request Quote Chat Now

Shenzhen BLH Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number lc

FC / SC / LC Singlemode G652 / G655 / G657 Fiber Optic Patch Cord

Specification:

*Single mode and Multimode

*Cable 0.9mm,2.0mm,2.4mm or 3.0mm with simplex or duplex and 4,6,8,12,24,48 cores

*Custom order length

*Cable color green , yellow , orange and customized

*All parts compliant with RoHS

*IEC standard compatible

*GR-326-CORE Compliant

Features:

Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability
Good in repeatability and exchangeability

Applications :
1. Communication Workshop
2. FTTH
3. Local Area Network
4. Fiber Sensor
5. CATV
6. Fiber Optical Communication System

Performance index:

Parameter

Unit

FC, SC, LC,ST fiber optic patch cord

ST, MU

MT-RJ, MPO

E2000

UPC

APC

UPC

APC

Insertion loss(typical)

≤ 0.3

≤ 0.2

≤ 0.3

≤ 0.2

≤ 0.3

≤ 0.2

≤ 0.3

≤ 0.2

≤ 0.3

Return loss

≥ 45

≥ 50

≥ 60

≥ 30

≥ 45

≥ 50

≥ 30

≥ 45

≥ 50

≥ 35

≥ 55

≥ 75

Operating wavelength

1310, 1510

Exchangeability

≤ 0.2

Vibration

≤ 0.2

Operating temperature

-40~75

Storage temperature

-45~85

Cable diameter

3.0, 2.0, 0.9

Availabilities:

Full specifications, FC, SC, ST, LC, MTRJ, E2000, etc.
Simplex and Duplex assemblies available
Singlemode and multimode available
PC, UPC and APC polishing available
PVC and LSZH outer sheath.
0.9mm, 2.0mm and 3.0mm cable size.
Hybrid patch cords are available upon request
Pigtail available
Loopback available
Customized length

Ordering Information:

(1)Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA, FDDI, ESCON
(2)Ferrule End-face: PC, UPC, APC
(3)Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um), OM3(10G)fiber
(4)Cable Quantity: Cable Quantity: Simplex, Duplex, 6cores ,12corns, 16cores, 24cores, 36cores, 48cores...
(5)Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
(6)Cable Length: 1, 2, 3 meter or customized(7)Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum ,Armored

Pictures

Payment and Delievery:

Payment : L/C, T/T, Western Union, Moneygram,Paypal as well as Cash acceptable

Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
