Help CenterCast Iron Flange Connection
US$ 15 - 1,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Material:
Iron
Technics:
Casting
Type:
Other, Plug, DIN
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Connection ValveUS$ 10 - 500MOQ: 50 Sets -
Cast Iron Flange Pipe ConnectionUS$ 10 - 500MOQ: 50 Sets
-
DIN CAST IRON FLANGE JOINTS PN10US$ 10 - 500MOQ: 50 Sets
-
Single Sphere High Performance Carbon Steel, Zinc Plated PN10 / PN16 Rubber Expansion JoinUS$ 10 - 1,000MOQ: 5 Pieces
-
FLANGED SINGLE SPHERE EXPANSION JOINT UNION TYPEUS$ 10 - 1,000MOQ: 5 Pieces
Material
Iron
Technics
Casting
Type
Other, Plug, DIN
Place of Origin
Shandong, China
Model Number
PC-016
Brand Name
DongSheng
Connection
Flange
Shape
Equal
Head Code
Other, rounded
Flange connection
MATERIALS LTST
| NO | PART NAME | MATERIAL |
| 1 | BODY | Grey cast iron GG25 |
| 2 | PLUG | BRASS H62 |
DIMENSION DIN STANDARD
SIZE mm |
F |
E |
L |
A |
B |
M |
G |
n-d |
40 |
102 |
16 |
51 |
150 |
110 |
88 |
40 |
4-18 |
50 |
99 |
18 |
49.5 |
165 |
125 |
103 |
50 |
4-18 |
65 |
108 |
18 |
54 |
185 |
145 |
123 |
65 |
4-18 |
80 |
113 |
20 |
56.5 |
200 |
160 |
138 |
80 |
8-18 |
100 |
120 |
20 |
60 |
220 |
180 |
158 |
100 |
8-18 |
125 |
130 |
22 |
65 |
250 |
210 |
188 |
125 |
8-18 |
150 |
142 |
22 |
71 |
285 |
240 |
214s |
150 |
8-22 |
200 |
168 |
24 |
79 |
295 |
295 |
269 |
200 |
8-22 |
DIMENSION NF STANDARD
SIZE |
F |
E |
L |
A |
B |
M |
G |
n-d |
40 |
106 |
16 |
53 |
150 |
110 |
88 |
40 |
4-18 |
50 |
107 |
18 |
53.5 |
165 |
125 |
103 |
50 |
4-18 |
65 |
124 |
18 |
62 |
185 |
145 |
123 |
65 |
4-18 |
80 |
133 |
20 |
66.5 |
200 |
160 |
138 |
80 |
8-18 |
100 |
138 |
20 |
69 |
220 |
180 |
158 |
100 |
8-18 |
125 |
144 |
22 |
72 |
250 |
210 |
188 |
125 |
8-18 |
150 |
152 |
22 |
75 |
285 |
240 |
214 |
150 |
8-22 |
200 |
170 |
24 |
100 |
340 |
295 |
269 |
200 |
8-22 |
