Hydraulic Noise Elimination Check Valve
US$ 10 - 100
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Other, Check, Check Disk valve
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Non-return Valves, Swing Check, Cast Iron, Comply to DIN 2533US$ 10 - 1,000MOQ: 50 Pieces -
Single Plate Swing Check Valve, American Standard Class125/Class150,cast Steel,stainless SteelUS$ 10 - 100MOQ: 10 Pieces
-
Stainless Steel Disk Check ValveUS$ 1 - 1,000MOQ: 50 Pieces
-
Stainless Steel Single Door Check Valve PN40US$ 10 - 100MOQ: 10 Pieces
-
Stainless Steel Disco Check Valve(Size 125-300)US$ 1 - 1,000MOQ: 1 Piece
Standard or Nonstandard
Standard
Structure
Other, Check, Check Disk valve
Pressure
Low Pressure
Power
Hydraulic
Material
Casting
Temperature of Media
Medium Temperature
Media
Water
Port Size
DN50~DN300
Place of Origin
Shandong, China
Model Number
H41X-16
Brand Name
DS
Application
General
1)Feature:
Silent lift check valve is suitable for water supply and drainage pipeline. It has small volume, light weight, small resistance, long service life etc.
2)MATERIAL LIST:
Pos |
Part |
Material |
1 |
Guide |
Ductile Iron GGG40 |
2 |
Body |
Cast lron GG25 |
3 |
GUIDING STEM |
Brass Cuzn40Pb2 |
4 |
Spring |
Stainless steel |
5 |
Seal |
NBR,EPDM,VITON |
6 |
Disc |
Ductile Iron GGG40 |
Application:
PN Nominal pressure |
1.6Mba |
Sealing test pressure |
1.76Mba |
Strength test pressure |
2.4Mba |
Suitable temperature |
EPDM:-10—+120°C NBR:-10—+80°C VITON:-23—+150°C SILICON:-50—+200°C |
Medium |
Fresh water ,sea water ,waste water,food stuff,steam,all kinds of oil,all kinds of acid and alkaline liquid etc |
