Fully Automatic Creasing and Die Cutting Machine Model SAM1300
Introduction :
Manufacturer of Cbaden Superior Machine Group design and build this Fully Automatic Creasing and Die Cutting Machine Model SAM1300 , we build this Machines for more than 12 years.
We try our best to meet the demands of clients. At present, various creasing and cutting machines can be offered. We passed ISO9001:2008 International Quality Management system certification
and CE certification. With high quality products and our perfect service, we have attracted customers from at home and abroad.
Fully Automatic Creasing and Die Cutting Machine Model SAM1300 is a special equipment for creasing and automatic die cutting ordinary cardboard corrugated board(Such as Brands, Invitation letters ,Paper File, Cartons, Bags, Mats, Name cards, Calendar/Mouse Pad/Cup/Cap/File/Gasket and so on),applicable to printing packaging decoration and plastic
industries. Machine is characterized by compact structure, fine workmanship, large pressure, high precision and easy and reliable operation, etc. Has fully automatic feeding,
die cutting, delivery, obstacle indicating , checking and measuring functions.
Machine photo:
More detail :
1. Pneumatic clutch, clutch quickly, large power transmission.
2. Pneumatic lock plate, positioning accuracy, reliable and convenient.
3. High Precision intermittent motion mechanism
4. More stable and reliable function with imported electrical appliances
5. PLC Controlled touching screen and fault showing system makes an easy and convenience operation.
6. Fully omnibearing adjustable design so that the pressure can be adjusted to a balance state at any time
7. More precise and stable location with front-back and left-right positioning mechanism
8. Circulate oiling system to avoid oil-lack operation of machine
9. Module design of complete machine.
10. Vernier device of front gauge makes a more speedy adjusting.
11. Greatly enhance the work efficiency thanks to the Non-stop working device when delivery paper and receive paper.
12. The main transmission device adopts helical gear transmission,
So that it has simple structure, high transmission efficiency and big pressing and cutting power.
13. More safe of CE Approved design.
14. It has Double papers, deflective paper, empty paper controlled system,ensuring reliable delivery paper and cutting paper precision
15. That photoelectric detection of Front rail and pull rail ensures paper accurate positioning
Technic parameter :
Model |
SAM1300 |
Max. Paper size |
13200*980mm |
Min. Paper size |
320*470mm |
Max. cutting size |
1330*990mm |
Cutting precision |
±0.2mm |
Speed |
5000pcs/h |
Height of paper feeding pile |
1400mm |
Height of paper delivery pile |
1200mm |
The main Motor power |
11kw |
Total power |
13.5kw |
Machine weight |
19T |
Machine dimensions |
7700*2350*2230mm |
Die Cutting Machine
More photos :
