Help Center2P 35A Electric Australian Weather Protected Isolating Switch
Related Products
-
Power Supply UKF Series Weather Protected Isolating SwitchesUS$ 4.22 - 4.7MOQ: 500 Pieces -
UKF Series Weather Protected Isolator Switch Leakage Protection Switch 2P 35AUS$ 4.31 - 4.8MOQ: 500 Pieces
-
IP56 Series UKF Weatherproof Weather Protected Isolator Switch 2P 35A UKF2-35US$ 4.31 - 4.8MOQ: 500 Pieces
-
2P 35A Series UKF Weather Protected Isolating SwitchesUS$ 4.31 - 4.8MOQ: 500 Pieces
-
1P 2P 3P 20A Weather Protected Isolating SwitchesUS$ 4.58 - 5.15MOQ: 500 Pieces
* Cables looped in and out from overhead
* In and out from underground
* In and out straight through the switch
* Two 25mm rear knockouts are moulded in the base for surface mounting with concealed wiring
Advantages:
* Be used for isolate to ensure the safety of maintenance work.
*Be used for certain circuit switching operation to change the system runs.
*Has superior waterproof and dustproof function, along with anti-corrosion, anti-UV, cold temperature, aging, etc.
*Has perfect protection to your safe for using of electricity in the rain, dust, freezing, high temperature, strong ultraviolet radiation and other harsh outdoor environments demand.
* It is suitable for any outdoor application conditions.
Model Number |
Parameter |
IP Rating |
UKF 4P-20 |
20A 440V Four pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 4P-35 |
35A 440V Four pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 4P-63 |
55A 440V Four pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 3P-55-32CE |
55A 440V Tripe pole, with 32mm conduit entry at each end terminals accommodate 16mm² cable, M Rating 160 |
56 |
UKF 3P-63-32CE |
63A 440V Tripe pole, with 32mm conduit entry at each end terminals accommodate 16mm² cable, M Rating 160 |
56 |
Model Number |
Parameter |
IP Rating |
UKF 1P-20 |
20A 250V single pole, surface switch, terminals accommodate 16mm² cable, M rating 220 |
56 |
UKF 1P-35 |
35A/63A 250V single pole, terminals accommodate 16mm² cable, M rating 220 |
56 |
UKF 1P-63 |
56 |
|
UKF 2P-20 |
20A 440V Double pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 2P-35 |
35A 440V Double pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 2P-63 |
63A 400V Double pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 3P-20 |
20A 440V Tripe pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 3P-35 |
35A 440V Tripe pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
UKF 3P-63 |
55A 440V Tripe pole, terminals accommodate 16mm² cable, M Rating 180 |
56 |
Product Type |
Package Size (CM) |
QTY/CTN (PCS) |
G.W (KGS) |
N.W (KGS) |
||
UKF 1P |
44.5 |
19.5 |
39 |
20 |
11 |
9.5 |
UKF 2P |
44.5 |
19.5 |
39 |
20 |
11 |
9.5 |
UKF 3P |
44.5 |
19.5 |
39 |
20 |
11 |
9.5 |
UKF 4P |
44.5 |
19.5 |
39 |
20 |
11 |
9.5 |
2. Distributoership are offered for your unique design and some our current models .
3. Protection of your sales area, ideas of design and all your private information .
4.We carry out your order into our well-organized production schedule, ensure your punctual delivery time.
5.Production report before your order packed.
6.Shipping notice and photos sent to you as soon as your order is shipped.
Q-1. Can i take some samples?
A: Yes, we support to take samples before place the order. Just feel free to contact with us if you have any requirements.
Q-2. Are you original Factory?
A: Yes, we have our own factory with many storage.
Q-3. How can you make sure the quality of the products?
A: We will accord to international quality standards to inspect every item before leaving our factory.
