Specifications
fiber laser marking machine price1.For gold, silver, precious metal
2.Rotary system
3.High precision
Fiber laser marking machine price :
Main Configuration
1. Germany IPG fiber laser source or China famous Raycus fiber laser Optional.
2. USA CTI Galvo scanner or China made optional
3. 100*100 mm working area or 200*200mm Optional
4. Portable structure or desktop model with wheels
5. 10w /20w laser power optional
6. Red light preview
7. Air cooling
8. Manual up & down worktable
9. Foot-switch equipped
10. Portable type equipped notebook with English system
Function:
Use to mark/printing and engrave on many type of different design text, symbol,pattern,bar code,2D code, serial number, and suitable for online marking
Fiber laser machine can work on the following material:
Many type of metals: Gold,copper,aluminum,stainless steel,chrome Brass,etc
Alloy and metal oxides
Some non-metallic materials:silicon wafer,ceramics, plastic, rubber, epoxy resin, ABS,Printing
ink,Plating,Spraying,Coating film and special surface treatment
Small Size,Better marking performance,easy to operate and maintenance free.
Applicated Industry
- Electrical Engineering and Electrical part and component
Specification
MODEL |
DW-10 / DW-20 |
Laser Power |
10W 20W optional |
Laser Brand |
German IPG fiber laser or China Raycus fiber laser optional(with different price) |
High speed Galvo Scanner |
USA made or China made optional |
Laser wave length |
1064nm |
Marking Area |
100×100mm 200×200mm optional |
Marking speed |
≤7000mm/s |
Marking depth |
0.05~0.5 mm (accord to the material) |
Minimum Line width |
0.01mm |
Minimum character |
0.1mm |
Cooling way |
forced air cooling |
General Power |
500W |
Power Supply |
220V/50Hz/1kVA 220V/60HZ 110v/60hz |
Proprietary software |
User friendly interface, easy operation |
set and deal different layers graphic in separate | |
Support PLT,PCX, AL, DXF, BMP,JPG formats file | |
compatible AutoCAD, CorelDraw, Photoshop etc software | |
Automatic serialization, date coding | |
letter,symbol, pattern, figure, image, bar code, 2D code auto arrangement and amendment | |
Optional device |
On-line flying marking, 3D dynamic marking,Rotary marking, accord to customer request |
Some spare parts :
We also have the CO2 /YAG laser marking machine :
Our service:
1.Online service.If any technical questions or problems,our engineers will help you give you solution on email or some online way.
2. Minimal one year for free warranty (include whole machine and spare parts)
3.Spare parts supplying on time or help fix the old parts.
4.Faster delivery,most of our products have stock and guarantee delivery within short time.
5.Free design and guide for customer
6.Free software update
