Metal Laser Cutting Machine YAG 500W

Name: Metal Laser Cutting Machine YAG 500W
Brand: Dwin
SKU: 127149461
Availability: InStock

US$ 36,000 - 42,000 MOQ: 1 Set

Key Specifications

Laser Type:

YAG

Place of Origin:

Shandong, China

Brand Name:

Dwin

Jinan Dwin Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Laser Type YAG

Place of Origin Shandong, China

Brand Name Dwin

Model Number DW-YAG-500

Specifications

metal laser cutting machine YAG 500W
1.ball screw and the servo motor
2.YAG Lamp Pump Solid Laser
3.high accuracy

metal laser cutting machine YAG 500W with the following features:

1. Reasonable Gantry Structure, stable laser path

2. Mechanical Following laser cutting head imported from USA, has high sensitivity and good stability.

3. Power supply controlled by control cabinet, easy to operate

Precise and rational design, optical adjustment for easy lamp and rod replacement
Japanese Panasonic servo motor to improve the cutting speed and stability.
The combine of high precision ballscrews drive system and advanced feed system.
High power and big refrigerating capacity water chiller.

Advantages of Large format gantry DW solid laser cutting machine

1. High precision in cutting. Excellent in stability.

2. High quality in cutting edge

3. Cutting large format and suitable for cutting more material.

4. Drawer and air valve for conveneintly work.

5. High performance-price ratio

6. Low cost for using

7. Higher cutting speed and efficiency

8. Low fees for the future maintain

Assisit air :

A gas assist through the metal cutting optics nozzle, is needed to pierce through the

metal and allows for a clean, smooth cut edge. The use of oxygen or nitrogen allows many

metals to be cut with a dross free edge, no deburring required. A lower piercing gas assist

pressure can be set in the software to minimize the chance of pierce blowouts in thicker metals

Model	DW1325
Working area :	130*250cm
Laser power :	500w
Laser type :	YAG solid-state laser optical system
laser wave length	1064nm
max Cutting speed :	2m/min
Power supply :	380V/50HZ-60HZ
Laser power injection	18KW
Water chiller power	5HP
X-axis and Y-axis Location accuracy	±0.05mm
X-axis and Y-axis repeat location accuracy	+- 0.05mm
Fast moving speed	5m/min
Min. cutting line width	0.18mm
Transmission Method	servo and the ball screw
Pulse width	0.1-10ms
Pulse frequency	1-300HZ
control system	Offline Motion Control
Min. cutting line width	0.2mm
Max cutting line width (carbon steel, stainless steel)	3mm
gross weight	2.5ton
