DW1325 cnc carving honey amber stone cutting machine
This series of models mainly used for heavy weight of the tile, bluestone, marble, granite, white marble, sandstone, such as a stone sculpture processing, category carved glass-cutting and engraving melting material.
Performance features
1. XYZ axis adopt imported Taiwan HIWIN square linear guide orbit two line sliding track heavy loading, stable working, hign precision, long lifetime.
2. X,Y,Z three-axis all have the waterproof, dustproof system
3. Whole seamless weld steel structure, not easy to distort , the table back lining is armor plate, good rigidity, the machine can bear 1MT weight at least.
4. Constant power spindle and motor, hightly cutting capability ,high efficiency.
5. Well compatibility, compatible sofetware CAD/CAM, such as Type 3, Artcam,Wentai ,Coredraw.
6. Double direction cutters cooling system can prolong the lifetime of using.
7. High flexility, uneasy distorted cable and imported electronic components guarantee the stablitity of operating the machines.
Standarded accessories
1.Spindle:4.5KW-9KW water cooling (Air cooling & Italy HSD for your choice)
2.Stepper motors (Servo motors, Japan Yaskawa and panasonic servo motors for your choice )
3.Taiwan Imported HIWIN or PMI square linear orbit
4.DSP or NCstudio control for your choice
5.Water tank, used for cooling the bits
6.Whole seamless weld steel structure
7.20 pieces of different size bits
Performance parameter
| 1 | X,Y Working area | 1300*2500mm( we can customize that for you) |
| 2 | Z Working area | 250mm |
| 3 | Table size | 1500mmx2900mm |
4 |
Processing precision | 0.05mm |
| 5 | Reposition precision | 0.02mm |
| 6 | Table structure | aluminium or steel for choice |
| 7 | X,Y,Z structure | X,Y,Z ball screw |
| 8 | Command | G CODE |
| 9 | Machine power | 2.5KW |
| 10 | Max processing speed | 6000mm/min |
| 11 | Max speed | 8000mm/min |
| 12 | Working voltage | AC380V/50Hz |
| 13 | Spindle power | 3.5KW |
| 14 | Spindle rotating speed | 0-24000rpm/min |
| 15 | Drive motor | Stepper (servo motor for choice) |
| 16 | Operation system | DSP system |
Machine overview
Samples
Packaging
for the machine our warrenty is
1.18 months warrenty for the whole machine( consumming parts are excluded)
2. CE FDA certification
3. 24 hours Professional Technical Person service for you.
4. Friendly English verson manual and operation video CD disc
Our sevice
we hold the concept that quality is our life, service is our persuit, customer is our priority, we have confidence we can give you our professional support with our 6 years of laser engraving cutting machine experience.
Before sale
Carefully listening to your requirement, checking every detail of your information and providing most helpful advices accordingly.
During sale
Strictly monitoring every process of production, dealing with all the packaging and shipping affairs, and solving all the problems.
After sale
Providing Friendly English version manual and operation video CD disc.
Solving every problems during using and maintenance.
Providing good after service calls from our professional technicians who speaks very good English.
Sending our technician abroad if there is big problem by any chance.
The after sale service is lifelong.
We accept every suggestion from you, and if you have any other need, we will do great efforts to meet it.
