HDR900-2000 Type Normal temperature normal pressure dual-inverter jig dyeing machine
1.Application
HDR900 series NT-NP jigger dyeing machine is one of the jigger dyeing machine with biggest rolling diameter and fabric width, this machine self designed and developed by our factory, and absorbs advantage of Korea jig dyeing machine, it is necessary dyeing machine for dyeing and printing industry.
This machine is suitable for pre/post processing and dyeing process for all kinds of textiles, such as cotton, ramie, chemical fiber under normal temperature normal pressure. Widely used in dyeing and printing industry in limited quantities and various kinds, set desizing, boiling, bleaching in one, advanced design, reasonable structure, wide adaptation, good performance, safe and reliable operation.
2.Technical parameter
| Roller diameter | 300mm |
| Max. rolling width | 1800mm |
| Max. rolling diameter | 880mm |
| Working speed | 20-200m/min |
| Fabric tension | 0-90kg |
| Working temperature | 105 degree |
| Liquor ratio | 1:3 |
| Vat capacity | 600L |
| Whole machine weight | 3.5T |
| Shape size | 3830*1886*2150mm |
