15mm*15mm 7.4 High Speed Low Cost Driving dc Coreless Motor Shenzhen Factory
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
1515RN 51-2-7.4
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Diamater 15mm Length 15mm Medical Coreless Micro Metal Brush MotorNegotiableMOQ: 10 Pieces -
16*20mm High Precision Long Lifetime PM dc Electric Coreless MotorNegotiableMOQ: 10 Pieces
-
15*15mm Small Coreless Motor Used in Medical Equipment,precisiom dc MotorNegotiableMOQ: 10 Pieces
-
16mm 6V 7000rpm Low Current Low Power CCW dc Coreless MotorNegotiableMOQ: 10 Pieces
-
7.4V 15mm 17590rpm CW Unmanned Plane High-end Mini Electrical Coreless MotorNegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Constar
Model Number
1515RN 51-2-7.4
Usage
Other, medical,health care and industrial automation., medical,health care and industrial automation.
Certification
CE, ROHS
Type
Micro Motor
Torque
2.5mNm
Construction
Other, precious metal commutation
Commutation
Brush
Protect Feature
Other, *
Speed(RPM)
17590rpm
Continuous Current(A)
952mA
Output Power
5.39W
Voltage(V)
7.4V
Efficiency
Other, *
15mm*15mm 7.4 high speed low cost driving dc coreless motor Shenzhen factory
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series |
Performance Code |
Commutation Structure |
Dimension (mm) |
Voltage (V) |
Termanal resistence (Ω) |
No-load Speed (rpm) |
No-load Current (mA) |
Load Torque (mNm) |
Load Speed (rpm) |
Load Current (mA) |
1515RN51 |
2-7.4 |
Precious Metal |
Φ15*15 |
7.4 |
2.5 |
25500 |
50 |
2.5 |
17590 |
952 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
