Home > Electrical & Electronics > Electric Motor > DC Motor > 16mm 6V 7000rpm Low Current Low Power CCW dc Coreless Motor
16mm 6V 7000rpm Low Current Low Power CCW dc Coreless Motor
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
1620RN51-3-6.0
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7.4V 15mm 17590rpm CW Unmanned Plane High-end Mini Electrical Coreless MotorNegotiableMOQ: 10 Pieces -
7000rpm 6V Metal Brush Precision dc Coreless Motor Made in ChinaNegotiableMOQ: 10 Pieces
-
16mm 6V Small High-end Precision Industrial Automation dc Motor CorelessNegotiableMOQ: 10 Pieces
-
15mm 7.4V Long Life Low Nise Precision Precious Metal Brush dc Electric MotorNegotiableMOQ: 10 Pieces
-
12*15mm Micro dc Coreless Motor,low Price Pecision UAV Electric MotorNegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Constar
Model Number
1620RN51-3-6.0
Usage
Other, medical,health care and industrial automation., medical,health care and industrial automation.
Certification
CE, ROHS
Type
Micro Motor
Torque
0.5mNm
Construction
Other, precious metal commutation
Commutation
Brush
Protect Feature
Other, *
Speed(RPM)
7000rpm
Continuous Current(A)
160mA
Output Power
0.48W
Voltage(V)
6V
Efficiency
Other, *
16mm 6V 7000rpm low current low power CCW dc coreless motor
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series |
Performance Code |
Commutation Structure |
Dimension (mm) |
Voltage (V) |
Termanal resistence (Ω) |
No-load Speed (rpm) |
No-load Current (mA) |
Load Torque (mNm) |
Load Speed (rpm) |
Load Current (mA) |
1620RN51 |
3-6.0 |
Precious Metal |
Φ16*20 |
6.0 |
16 |
11000 |
45 |
0.5 |
7000 |
160 |
5-6.0 |
Precious Metal |
Φ16*20 |
6.0 |
19.2 |
9200 |
20 |
0.5 |
5500 |
150 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
