IP67 Miniature Snap Action Switch as Good as Omron

Name: IP67 Miniature Snap Action Switch as Good as Omron
Brand: HUSHUN
SKU: 127104303
Availability: InStock

US$ 1.5 - 3 MOQ: 200 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HUSHUN

Model Number:

LXW-8A

Guangdong Hushun Electric Appliance Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHUNDE

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HUSHUN

Model Number LXW-8A

Max. Current 5A

Max. Voltage 250VAC

Operating Temperature -40 TO 90

Protection Level IP67

Part name:LXW-8A

Specifications

Item		LXW-8A
Operation speed (linear speed)		0.1-1mm/s
Operation frequency	Mechanics	30times/min
	Electrical appliances	15 times/min
Insulation resistance		100MΩ(min) when 500VDC
Connect impendence		50MΩ(outside cable is 100MΩ)
Electric medium		1000VAC 50HZ in the same two poles testing for 1 minute 1500V/1min
		1500VAC 50/60HZ around metal handle testing for 1 minute
		1500VAC 50/60HZ on two points (no sheet metal) testing for 1 minute
Vibration		Product malfunction: 10-50HZ, 1.5mm double swing
Impact resistance		Destroy: 400m/s (max)
		Malfunction: 300m/s (max)
Estimated life		Mechanics min: 300000 times
		Electron min: 100000 times
Protect degree, distinction		IP67 is outside cable, IP50 is welding point connection
Protect degree comparatively electron impact		Grade one
Penetrate endurable index		175
Around temperature		-40°C-90°C
Around humidity		Max 95%(5°C-35°C)
Weight		LXW-8A about 10g (no lever switch) LXW5-FS about 3g (no lever switch)
