Product:waterproof switch ,watertight miniature snap action switch, waterproof microswitch
Model:LXW-8A (for lead wire types)
Scope of Application
LXW-8A Dustproof & Waterproof Inching Switch Series are applicable for the 50Hz, 220V AC power supply or up to 30V DC power supply in the condition of water splash or of plentiful dust, functioning as the on/off switch or limit switch of a control circuit. This series switches use airproof materials which has strong insulation and good waterproofed, its protection grade is up to IP67. It is widely used in cars, agriculture machines and equipments which in special environment, can endure worse environment, have good precision and longer usage life.
characteristic and parameter
1.characteristic
Item |
LXW-8A |
|
Operation speed (linear speed) |
0.1-1mm/s |
|
Operation frequency |
Mechanics |
30times/min |
Electrical appliances |
15 times/min |
|
Insulation resistance |
100MΩ(min) when 500VDC |
|
Connect impendence |
50MΩ(outside cable is 100MΩ) |
|
Electric medium |
1000VAC 50HZ in the same two poles testing for 1 minute 1500V/1min |
|
1500VAC 50/60HZ around metal handle testing for 1 minute | ||
1500VAC 50/60HZ on two points (no sheet metal) testing for 1 minute | ||
Vibration |
Product malfunction: 10-50HZ, 1.5mm double swing |
|
Impact resistance |
Destroy: 400m/s (max) |
|
Malfunction: 300m/s (max) | ||
Estimated life |
Mechanics min: 300000 times |
|
Electron min: 100000 times | ||
Protect degree, distinction |
IP67 is outside cable, IP50 is welding point connection |
|
Protect degree comparatively electron impact |
Grade one |
|
Penetrate endurable index |
175 |
|
Around temperature |
from -40 to 90degrees Celsius |
|
Around humidity |
Max 95%(5 to 3 degrees Celsius) |
|
Weight |
LXW-8Aabout 10g (no lever switch) LXW5-FS about 3g (no lever switch) |
|
