SPECIAL FEATURES& APPLICATIONS :
The lockstitch free-arm machines of class 205 shows their strength in case of difficult sewing operations on three-dimensional workplaces, e.g. when processing thick leather the production of home upholstery and object furniture. Their
heavy,extremely sturdy design and the especially efficient and powerful triple feed ensure a maximum sewing quality,
particularly when using extremely thick fabrics and threads.
- Excellent stitch pattern and constantly tight stitches
- constant stitch lengths due to optimized triple feed kinematics
- long stitch lengths up to 10mm
- high top feed stroke and high sewing foot stroke
- unhindered handling of bulky workpieces
- always perfect seam appearance and exact seam contours by means of expert adaption of sewing equipment and
- fabric guides
- long sewing cycles by barrel shuttle with large bobbin capacity
- Suitable for stitching all the extra heavy-weight materials,such as the handle of bags,gloves, safety belts,tents,seatings,shoes,bags,……etc.
SPECIFICATIONS :
Model No. : gw-205
Max.stitch length : 10mm
Max.sewing speed : 800 R.P.M
Presser foot lift : By hand 13mm , By knee 20mm
Needle bar stroke : 56mm
Needle system : DD*1
Sewing are : 320mm*185mm
three table adge can be choose
Weilishi Machine Co.,Ltd established in 1993, is located in Zhejiang Province Huzhen Town with convenient transportation networks.Covering an area of 18,000 square meters,our company staffs more than 200 workers.
Our major products includes post bed sewing machine,lock stitch sewing machine,leather round knife cutting machine,cylinder bed with unison feedlockstitch sewing machine.Under the brand of WINPARD GOLDWELL. our products are enjoying high prestige in more than 30 countries and regions.
We have passed the evaluation of ISO9001 Quality Control System and MS certificate,CE certificate. We sincerely hope to cooperate with customs from all over the world.
We are looking forward to building up mutually beneficial business relationships with your companies in the future.
