AutomaticCompact Filling Line For Injection And Liquid Medicine

AutomaticCompact Filling Line For Injection And Liquid Medicine photo-1
US$ 18,000 - 24,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Medical
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Medical
Packaging Type Bottles
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380v
Power 9KW
Place of Origin Shanghai, China
Brand Name shengsen
Model Number SS-1825
Dimension(L*W*H) 8000*1300*1800
Weight 750kg
Certification GMP
After-sales Service Provided Engineers available to service machinery overseas



Brief Introduction:
1.This line is composed of bottle feeding machine ,cylinder ultrasonic washing machine ,filling  stoppering machine,capping machine and labeling machine etc.
2.This line is applied to 20-500ml bottle feeding,dry and sterilizing ,filling stoppering ,capping and labeling.Only changing some mould the machine could be applied for different size bottles.
3.The line is applied for glass or plastic bottle;it has a wide application and easy adjustment ,widely used in injection and vaccine,etc.
4.The yield capacity of the whole line depends on the bottle size ,shape and liquid viscosity.
5.The tunnel sterilizer ,protection covers and laminar flow are for optional.
Parameter

Application   20-500ml
 Yield Capacity 40-60  pcs/min
                           80-120pcs/min
   Cleanness >99%
 Filling Tolerance 0-2%
Qualified stoppering rate ≥99%
Qualified cap putting rate ≥99%
Qualified capping/screw capping rate ≥99%
Power Supply 380V ,50HZ
Power 9KW
Dimension 8000(L)×1300(W)×1800(H) mm



 AutomaticCompact Filling Line For Injection And Liquid Medicine



Packaging & Shipping

 AutomaticCompact Filling Line For Injection And Liquid MedicineAutomaticCompact Filling Line For Injection And Liquid Medicine





Our Services

  We provide engineers available to service the machinery overseas.
