Specifications
Automatic Shrink Labeling Machine 250BPM was used for cutting the label and sleeve label onto bottle body and shrink it by steam
Automatic Shrink Labeling Machine 250BPM
Product introduction:
Automatic Shrink Labeling Machine 250BPM---The shrink labeling machine was used for cutting the label and sleeve the label onto bottle body and shrink it by steam. The whole process is automatic and was controlled by PLC. The shrink labeling machine is including steam generator and steam tunnel.
Product feature:
1. Optical-mechanical integration design, Mitsubishi electric control system, easy in operation, work reliably, high automatic degree.
2. Advanced bottle-allocating device instead of the former screw bottle-allocating device. The space between bottles are controlled accurately. No bottle gripped or fall down, milled condition.
3. Man-machine conversation operation, make it more convenient.
4. Auto examination device is applied, if there is no sleeve label signal, the machine will be in semi-sleep condition automatically. Decrease running speed and spoilage, prolong the life of machine. In additional, main electric control element apply SIMENS of Germany. Making the quality more ensured.
5. Large application scope, in effective diameter range, round, square or other abnormity PET, glass bottle etc can be used.
Technical Parameter:
Model |
SL-250 |
Production speed |
250B/M(adjustable) |
Bottle diameter |
30mm -125mm (special bottle, special design) |
Bottle height |
30mm-350mm |
Bottle shape |
round, square, elliptic, rectangular etc |
Label length |
30mm -250mm |
Label thickness |
0.03mm - 0.13mm |
Label material |
PVC.PET.OPS |
Labeling machine size |
L3200×W850×H2070mm |
Main machine power |
3Kw |
Product name:
Shrink labeling machine, labeling machine, automatic shrink labeling machine, shrink machine, label shrink machine
Product details pictures:
Bottle mouth sleeve label machine
Sleeve labeling machine
Inside of sleeve label machine
Label sleeved and shrinked bottle
