Automatic Juice Machine/Juice Bottling Machine
Introduction of juice bottling machine:
The automatic juice bottling machine was used for hot filling for green tea, black tea, wulong tea, juice, juice drink, fruit juice, juice beverage,milk, milk drink and so on non-gas liquid.
The juice machine is combined with bottle washing, hot bottling and capping in one body. The whole process is automatic. It is suitable for glass bottle and plastic bottle to fill juice, mineral water, pure water, if add temperature control device, even for hot filling. The adjustment for bottle type of each unit is fulfilled by turning handle; it is simple, easy and quick. The filling method applies new micro pressure filling so that the filling speed becomes more quick and stable.
The features of automatic juice bottling machine:
1. The machine applies advance Mitsubishi programmable controller (PLC) to control machine's auto-running
2. With lubricating oil automatic filling device
3. Washing part: Spray bottle by bottle clamp and machine hand and complete with rotating sealing inner and outer washing, backwater device
4.Capping part: Magnetic torsion tooth screw capping head, when the torque force more than the adjusted magnetic, the capping head will slip. Ensure screw tighten not hurt cap.
5.Starwheel with safeguard and alarm device, no bottle not filling , no cap not capping
Technical Parameter of juice machine:
| Model | RCGF14-12-5 | RCGF16-12-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 | RCGF40-40-12 | RCGF50-50-12 | RCG60-60-15 |
| Capacity(bph) | 2000-3000 | 2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-20000 | 20000-24000 | 25000-30000 |
| Filling precision | ±3 (liquid level) | |||||||
| Rinsing pressure | 0.3Mpa | |||||||
| Suitable bottle dimater | φ40-φ120mm | |||||||
| Suitable bottle height | 130-340mm | |||||||
| Suitable cap type | plastic screw cap, sport cap, aluminium cap etc | |||||||
| Motor power | 2.2kw | 2.2kw | 2.75kw | 3kw | 5.5kw | 7.5kw | 11kw | 15kw |
| Weight | 2300kg | 2500kg | 3500kg | 4500kg | 5500kg | 7500kg | 9800kg | 12800kg |
Automatic Juice Machine/Juice Bottling Machine
Juice bottling machine pictures:
Washing part for spray washing bottle inside with sterilized water, rotary type
Red tea filling part, hot filling with filling tank, this filling type is very stable. Filling by gravtiy, not pump. Pump filling is easy to generate foam. This filling type not easy genetate foam.
Capping head part, good sealing effect , copy italy and improved by our engineer
Bottled red tea
Appliance components of automatic juice machine:
Juice/Tea production line:
Pure water/mineral water treatment system---mixing part---sterilization----hot filling 3in1---reverse bottle sterilizer---spray cooling---labeling--- code printer---film packing or carton----end product
We can provide whole juice/tea production line
...
