1. PRODUCT FEATHRES
Model: MR50
Brand Name: MOUNTAIN RAISE
Engine: Cummins 4BTA3.9-C100
Structure: Articulated
Payment Terms: L/C, T/T
1) achievement based on Chinese and Australian technologies.
2) standard Cummins 4BTA39-C100 engine ensures reduced noise generation and low emission.
3) full hydromechanical transmission, and full hydraulic steering system.
4) double-axle six-wheel drive system, has a large hauling capacity, as well as improved safety and stability.
5)The articulated body design contributes to reduced turning radius.
6)The Glamour luxurious seat ensures great drive comfort.
7)The joystick of the product is designed on the basis of German ZF technology to achieve reliable performance.
8)six-wheel drive lift trucks are is adaptable to various surface conditions. operating on the soft soil, grass land, mine sites, and many other roughed terrains.
9)Available with a broad range of attachments to extend its working capacity for heavy duty mining projects.
3. PARAMETER
| Rated load | 5000kg | |
| Load center distance | 500mm | |
| Max. Lifting height | 3000mmm | |
| Freedom lift height | -- | |
| Portal frame inclination front/rear | 6°/12° | |
| Max. Running speed | 20km/h | |
| Max.lifting speed | 300mm/s | |
| Max. traction force (full load) | 30KN | |
| Max.gradeability (full load) | 20% | |
| Min. turning radius | 4980mm | |
| Length | Without fork | 4300mm |
| With fork | 5750mm | |
| Width | 2230mm | |
| Height | Portal frame height | 2900mm |
| Cabin height | 2950mm | |
| Max.lifting height | 4367mm | |
| Min. ground clearance | 310mm | |
| Operating weight | 9535kg | |
| wheelbase | 2280mm | |
| Front Tread | 1630mm | |
| Rear Tread | 1550mm | |
| Front overhang | 880mm | |
Shandong Mountain Raise Heavy Industry Machinery Co.,LTD located in one of the nine states ofancient ChinaQingzhou City, Shandong Province, owning a professional maintenance team with senior technicians,ready to provide support services to users and dealers. Select regular manufacturers for supporting spare parts, axle, transmissions and other main parts designed and produced by ourselves.
The company's sales and service network throughout the whole country 26 provinces, municipalities
and autonomous regions, and export to of Belgium, Germany, Britain, France, the Netherlands, Finland, Syria, Sweden, Kazakhstan, South Africa, Egypt, Mexico, Australia and other European and
international market.
1) We have 1 year warranty from the date of receiving the loaders.
2) During Warranty, if there is any part broken , we will send good and new parts for your replacements.
3) If out of warranty, we can provide 5+ years spare parts for you
4)We are 24 hours online, if you met some situation in a hurry, then contact with us anytime as you like, we will solve it as soon as possible.
