Home > Products > New Products > Tablecloth cutting engraving Machine / co2 laser machine website:nancyhyy88
Tablecloth cutting engraving Machine / co2 laser machine website:nancyhyy88
- 200 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, Other, Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, film switch |
Cutting Thickness: | 20mm | Cutting Area: | 1500*900 | Cutting Speed: | 800mm/s |
CNC or Not: | Yes | Cooling Mode: | Water Cooling | Control Software: | PLC |
Graphic Format Supported: | AI, BMP, DST, DXF, PLT, Other, AI, BMP, DST, DXF, PLT, HML | Place of Origin: | Jiangsu, China | Brand Name: | Chanxan |
Model Number: | CW-1590 | Certification: | CCC, CE, ISO, SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Tablecloth cutting Engraving Machine
1.1590;OEM,
2,all-purpose
3,Factory outlet,Best price
Applicable industry:
Tablecloth/ Bed Sheet Laser Engraving Machine is suit for cutting of ready-to-wear in garment industry,clothing cut pieces,clothing punching,cutting of leather products,cutting of wedding dress material,hot cutting,carving,engraving of various textile can choose CW-1509 high quailty chiffon dress laser cutting system.
Technical parameters:
Model: | CW-1509 |
Processing area: | 1500 mm x 900 mm |
Laser power: | 60W-80W |
Laser type: | Closed CO2 laser tube |
Cutting speed: | 0-800mm/s |
Engraving speed: | 0-1000mm/s |
Position accuracy: | <0.02mm |
Image format: | DXF/ PLT / BMP/ AI / HML / DST |
Work voltage: | 220 ±10% 50Hz(60Hz) |
Cooling system: | Enforce water cooling and protect system |
Whole machine power: | 1500W |
Weight: | 330KG |
Work temperature: | 1°C-45°C |
Work humidity: | 5% - 95% Non-condensate water |
Machine size: | 2100 x1500x1100 mm |
Machine parts: | |||||
Name | Amount | Units | |||
Water pump CW-5000 | 1 | set | |||
Air pump | 1 | pcs | |||
Power line | 2 | pcs | |||
Smoke pipe | 2 | pcs | |||
Water pipe with Air pipe | 2 | pcs | |||
centrifugal blower | 1 | pcs | |||
Inner hexagon spanner | 1 | set | |||
Plugs and Socket | 1 | pcs | |||
Tools bag: | |||||
Name | Amount | Units | |||
Manual book | 1 | pcs | |||
Software CD | 1 | pcs | |||
COM or USB line | 1 | pcs | |||
Tape for adjusting laser light | 1 | pcs |
Jona here,For best machine price,more machine pictures and videos,kindly find me as follows,
Skype :nancyhyy88 Wechat:623123705 Mob/Whatsapp:008615850106700
You will receive the best service. ♥♥♥♥♥
