RIG Flange ceramic 500 ohm resistor
|
RIG high power resistor Pictures:
| |||||||
|
RIG Dimentions: 500W:
400W:
250W:
| |||||||
| RIG high power resistor data sheet: | |||||||
| Electrical Characteristics |
Range of nominal resistance | 10Ω~500Ω | |||||
| Resistance tolerance | ±2%, ±5% | ||||||
| Frequency | 0 ~2GHZ |
||||||
| Wistand Voltage | 500V/1mm | ||||||
| Insulation resistance | ≥ 1GΩ |
||||||
| Standing wave rate | 1.2-1.3 | ||||||
|
Characteristics |
Rated power | 1-1200W | |||||
| Temperature range | -55°C~+165°C | ||||||
| TCR | ±300×10-6/°C | ||||||
| Temperature shock | ΔR≤±5%R |
||||||
| Moisture proof | ΔR≤±5%R |
||||||
| Vibrition(10-500HZ,0.75mm,6h) | ΔR≤±3%R |
||||||
| Test at low temperature(-55 °C,24h) | ΔR≤±5%R |
||||||
| Collision | ΔR≤ ±3%R |
||||||
| Physical Characteristics |
Terminal strength | (10N,5s) | |||||
| Solderability(240 °C,3S) | 95% |
||||||
| |||||||
