5 Watts DPMR Digital Two Way Radio With DTMF PTT-ID Scrambler TG-DP9000

5 Watts DPMR Digital Two Way Radio With DTMF PTT-ID Scrambler TG-DP9000 thumbnail-1
5 Watts DPMR Digital Two Way Radio With DTMF PTT-ID Scrambler TG-DP9000 photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
QuanSheng handheld type dpmr uhf walkie talkie
Model Number:
TG-DP9000
Contact Supplier Request Quote Chat Now
Fujian Nanan Quansheng Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen / shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name QuanSheng handheld type dpmr uhf walkie talkie
Model Number TG-DP9000
Type Handheld
Dimensions 133 X 60X 38mm
Frequency Range 136-174/400-470MHz
Storage Channel 16
Talk Range 5-8km

5 watts DPMR digital two way radio with DTMF PTT-ID scrambler -Quansheng TG-DP9000

5 watts DPMR digital two way radio with DTMF PTT-ID scrambler

01. Analog + digital dual mode
02. Auto switch between analog and digital
03. Jacklight
04. Display battery level
05. PC programmable
06. Voice prompt(Chinese/English)
07. H/M/L output power selective
08. Busy channel lock
09. Time-out timer(TOT)
10. Selective call
11. PTT ID
12. Lone work
13. Automatic link
14. Remote kill
15. Alarm
16. Scan
17. Built in VOX
18. Cable clone
19. CTCSS/DCS
20. Talk around
21. Reverse
22. 1750 code
23. Single call/Group call
24. Scrambler


General

Frequency Range                                                                       UHF: 400-470MHz

Channel                                                                                       16

Operating Voltage                                                                      7.2V

Antenna Impedance                                                                   50Ω

Operating Temperature                                                             -25°C~+65°C

Frequency Stability                                                                    ±2.5ppm

Battery                                                                                         Standard: 2500mAh(Polymer Li-ion)

Dimensions(H*W*D)(without antenna)                                     133 X 60X 38mm

Weight(with antenna and battery)                                            256.5g



Transmitter

Output Power                                                                              5W

Modulation                                                                                  11KΦF3E

4FSK Digital Modulation                                                            12.5KHz data only:7K6   FXD

                                                                                                      12.5KHz data and voice:7K6   FXW

Spurious Emission                                                                      -36dBm<1GHz

                                                                                                      -30dBm>1GHz

Modulation Limit                                                                         ±2.5KHz

FM Noise                                                                                      40dB

Adjacent Power                                                                           60dB

Audio Response                                                                         +1~-3dB

Audio Distortion                                                                          ≤3%

Digital Voice Encoder                                                                 AMBE+2C



Receiver

Sensitivity (Analog)                                                                    -123dBm(12dB SINAD)

Sensitivity(Digital)                                                                      -119dBm(BER5%)

Adjacent Channel Selectivity                                                    60dB

TIA-603

ETSI

Intermediation                                                                             70dB

TIA-603

ETSI

Spurious Response Rejection                                                  70dB

TIA-603

ETSI

S/N                                                                                                43dB

Rated Audio Power Output                                                        0.5W

Rated Audio Distortion                                                               ≤5%

Audio Response                                                                          +1~-3dB

Conducted Radiation                                                                 <-57dBm



5 watts DPMR digital two way radio with DTMF PTT-ID scrambler TG-DP9000







QuanSheng is one of the lead manufacturer of handheld radios

Design & manufacture 2 way radio for 20 years,

With ISO, CE, FCC and Rohs,

Taking 30,000 square meters,

with 500 people, 7 product line, and 9 SMT lines.

Export 1,000,000 pcs radios to 60 countries each year.
