Roof-mounted light tower with camera/telescoping light mast/vehicle mounted light tower

Specifications

Roof-mounted light tower with camera/telescoping light mast/vehicle mounted light tower



Roof-mounted light tower with camera/telescoping light mast/vehicle mounted light tower

vehicle roof-mounted light tower,telescopic mast light, vertical light tower,mobile tower, firefighting light , pneumatic mast

Model BSD-L18 roof-mounted light tower



Model BSD-L18 is a vehicle-mounted and omni-directional lift light for night emergency researched and developed by our own company. It absorbs advanced product structure from abroad and integrates our own ideal to design and improve. It is characterized by manual long-distance control, automatic reset, reliable performance, convenient operation, advanced design and so on.



This system, applied for night emergency, could be installed on cars or something fixed with omni-directional position. It has found increasingly wide application in such emergency light as rush-repair for engineering and disaster, fire illumination and police spot investigation for night operation.



Features:

l It is easy to operate and adopted by two control ways: wire and wireless.

l High airproof: pneumatic lift mast can stay stable on top for 24 hours with elegant appearance and steady lift.

l Long lifetime: it adopts imported lamp with its illumination time reaching above 10,000 hours.



Scope of application:

Engineering vehicles, fire flood lighting vehicles, accident reconnaissance vehicles, traffic patrol vehicles, traffic saving vehicles and various commanding vehicles to provide movable lighting.







Technical Parameters

Type model	Supply voltage(V)	Supply current(A)	Rotating angle (horizontal and vertical)	Light power(W)	Lamp tube brand	Extension height of light mast(mm)	Luminous flux (Lm)
BSD-L182150	DC12 / DC24	28	420°	150×2 (Metal halide lamp)	Philips	2,800	22,000
BSD-L182500	AC220	8		500×2 (metal halide lamp			92,000
BSD-L1821000		9		1000×2 (Halogen lamp)			40,000
BSD-L1841000		18		1000×4 (Halogen lamp)			80,000





Product Introduction



Excellent Operating System

It adopts pneumatic control device with high airproof, which could work 24 hours continuously without adding pressure.

Long-distance and wide-range illumination

It adopts manual long-distance control with valid distance 400 meters. Within 120 meters it is available to read newspapers and search all objects around.

Automatic recovery device

It is equipped with over-voltage, over-current and automatic recovery protection control device which could prevent circuit damage caused by improper operation.

Pressure safety device

The pressure safety control device, designed and took the lead in the world, could prevent mistake startup from collision of foreign bodies to pressure switch in the high-speed movement.

Strong illumination and Long lifetime

It adopts dysprosium lamp with the brightest light in the world. The luminance of single-lamp could reach 46,000LX and the life could arrive to 10,000 hours.

High temperature resistance

The lampshade is made of special hot-pressure glass with its transparency as twice as common one. It characterizes high temperature resistance and not-easy-to-break.

Waterproof and dustproof

The part switches of controller all imported possess high performance of waterproof and dustproof functions with protection grade IP66.
